239-1711 TANK & FILTER GP-HYDRAULICS/N MDE1-UP; JGZ1-UP

Group No: 239-1711
Part NumberPart NameQty
4B77391 PLUG-DRAIN1
4I53942 SENDER AS-TEMPERATURE (HYDRAULIC OIL)1
4I5490SCREW-MACHINE (M4X0.7X6-MM)2
0950826LOCKWASHER2
4J52673 SEAL-O-RING1
8H98194 ADAPTER-PLUG1
09516085 SEAL-O-RING1
21306776 SWITCH AS-LIQUID LEVEL (HYDRAULIC OIL)1
9X3401PIN-CONNECTOR (16-GA TO 18-GA)2
1028802KIT-RECEPTACLE (2-PIN)1
22705907 BREATHER (HYDRAULIC TANK)1
22706208 GAUGE GP-SIGHT (HYDRAULIC OIL LEVEL)1
245540210 COVER AS1
259092211 SCREEN GP-HYDRAULIC (TANK)1
272455612 SUPPORT AS1
275136213 BRACKET1
207640314 PLUG1
207640415 WASHER (49.5X60.5X1.5-MM THK)1
095173016 SEAL-O-RING1
126207517 FILTER GP-OIL (HYDRAULIC, CASE DRAIN)1
158898718 FILTER & VALVE GP-PILOT (HYDRAULIC OIL)1
164556719 COUPLER AS-QUICK DISCONNECT (MALE)1
3J1907SEAL-O-RING1
6V3965FITTING (QUICK DISCONNECT)1
164559020 VALVE AS-FLUID SAMPLING (HYDRAULIC OIL)1
3J7354SEAL-O-RING1
8C3446VALVE-SAMPLING1
165325621 PIPE AS1
188414022 FILTER GP-OIL (HYDRAULIC RETURN)1
2B085823 PLUG-PIPE1
2M084924 WASHER-HARD (13.5X25.5X5-MM THK)2
3D282425 SEAL-O-RING1
3K036026 SEAL-O-RING1
4J052727 SEAL-O-RING1
5C955328 BOLT (M6X1X16-MM)4
6D915729 SEAL-O-RING1
6J268030 SEAL-O-RING1
6V085231 CAP-DUST1
8C345132 CAP-DUST (HYDRAULIC OIL)1
8T026733 BOLT-SOCKET HEAD (M6X1X12-MM)2
8T412134 WASHER-HARD (11X21X2.5-MM THK)14
8T413635 BOLT (M10X1.5X25-MM)4
8T413736 BOLT (M10X1.5X20-MM)6
8T418337 BOLT (M12X1.75X40-MM)2
8T419538 BOLT (M10X1.5X30-MM)4
8T422339 WASHER-HARD (13.5X25.5X3-MM THK)4
8T422440 WASHER-HARD (8.8X16X2-MM THK)4
8T490841 BOLT (M8X1.25X25-MM)4
8T495642 BOLT (M12X1.75X35-MM)4
9X825643 WASHER (6.6X12X2-MM THK)4
