System And Components
260-8006 LINES GP-FRONT -AUXILIARYS/N A6F1-UP; A8F1-UP
Group No: 260-8006
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 7Y3731 | 1 FLANGE | 1 | |
| 1021248 | 2 HOSE AS | 1 | |
| 1772653 | 3 VALVE GP-RELIEF (LINE)(LINE, WORK TOOL) | 1 | |
| 2661217 | 4 HOSE AS | 1 | |
| 2043737 | 5 FLANGE-SPECIAL | 1 | |
| 2048137 | 6 BLOCK | 1 | |
| 2125148 | 7 BLOCK | 1 | |
| 2181139 | 8 BLOCK | 1 | |
| 2448522 | 9 HOSE AS | 1 | |
| 2607872 | 10 SUPPORT AS | 1 | |
| 2608043 | 11 BLOCK | 1 | |
| 2967069 | 12 SUPPORT AS | 1 | |
| 2967067 | 13 SUPPORT AS | 1 | |
| 2660912 | 14 BRACKET | 1 | |
| 2660913 | 15 SUPPORT AS | 1 | |
| 2661071 | 16 SUPPORT AS | 1 | |
| 0998232 | 17 SEAL-O-RING | 2 | |
| 1017402 | 18 BOLT-SOCKET HEAD (M12X1.75X30-MM) | 4 | |
| 1017404 | 19 BOLT-SOCKET HEAD (M10X1.5X30-MM) | 8 | |
| 1488323 | 20 CONNECTOR AS | 1 | |
| 2S4078 | SEAL-O-RING | 1 | |
| 5K9090 | SEAL-O-RING | 1 | |
| 6V9875 | CONNECTOR | 1 | |
| 1488352 | 21 ELBOW AS | 1 | |
| 5K9090 | SEAL-O-RING | 1 | |
| 6V9854 | ELBOW (SWIVEL) | 1 | |
| 1488411 | 23 PLUG AS | 1 | |
| 3K0360 | SEAL-O-RING | 1 | |
| 9S4185 | PLUG (3/4-16-THD) | 1 | |
| 1488429 | 24 TEE AS | 1 | |
| 5K9090 | SEAL-O-RING | 2 | |
| 6V9840 | TEE-SWIVEL | 1 | |
| 1644180 | 25 PLUG AS | 3 | |
| 7M8485 | SEAL-O-RING | 1 | |
| 9S4181 | PLUG (1-5/16-12-THD) | 1 | |
| 1734664 | 26 FLANGE | 1 | |
| 1P3703 | 27 SEAL-RECTANGULAR | 5 | |
| 5K9090 | 28 SEAL-O-RING | 3 | |
| 5P7468 | 29 CLIP (SLOT) | 2 | |
| 5P7469 | 30 CLIP (TAB) | 2 | |
| 6V1874 | 31 GROMMET (31-MM ID) | 2 | |
| 8T4121 | 32 WASHER-HARD (11X21X2.5-MM THK) | 8 | |
| 8T4136 | 33 BOLT (M10X1.5X25-MM) | 6 | |
| 8T4176 | 34 BOLT (M12X1.75X90-MM) | 4 | |
| 8T4196 | 35 BOLT (M10X1.5X35-MM) | 2 | |
| 8T4223 | 36 WASHER-HARD (13.5X25.5X3-MM THK) | 26 | |
| 8T4956 | 37 BOLT (M12X1.75X35-MM) | 6 | |
| 8T5092 | 38 BOLT (M12X1.75X150-MM) | 8 | |
| 2076222 | 39 BLOCK | 1 | |
| 1488335 | 40 CONNECTOR AS | 1 | |
| 5K9090 | SEAL-O-RING | 1 | |
| 6V8635 | CONNECTOR | 1 | |
| 7M8485 | SEAL-O-RING | 1 | |
| 8T7811 | 41 BOLT-SOCKET HEAD (M12X1.75X50-MM) | 4 | |
| 8T4183 | 42 BOLT (M12X1.75X40-MM) | 8 |
