System And Components
260-8007 LINES GP-FRONT -SYSTEM 3, 1-WAY, 2-PUMPS/N A6F1-UP; A8F1-UP
Group No: 260-8007
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 7Y3731 | 1 FLANGE | 1 | |
| 1021248 | 2 HOSE AS | 1 | |
| 1053477 | 3 BOLT-SOCKET HEAD (M10X1.5X45-MM) | 4 | |
| 1772653 | 4 VALVE GP-RELIEF (LINE) | 1 | |
| 2661217 | 5 HOSE AS | 1 | |
| 2076222 | 6 BLOCK | 1 | |
| 2125148 | 7 BLOCK | 2 | |
| 2181139 | 8 BLOCK | 1 | |
| 2607872 | 9 SUPPORT AS | 1 | |
| 2608043 | 10 BLOCK | 1 | |
| 2967069 | 11 SUPPORT AS | 1 | |
| 2967067 | 12 SUPPORT AS | 1 | |
| 2660912 | 13 BRACKET | 1 | |
| 2660913 | 14 SUPPORT AS | 1 | |
| 3258865 | 15 SUPPORT AS | 1 | |
| 2661278 | 16 BLOCK | 1 | |
| 2661279 | 17 FLANGE | 1 | |
| 2661303 | 18 HOSE AS | 1 | |
| 3174712 | 19 HOSE AS | 1 | |
| 2751439 | 20 BLOCK | 1 | |
| 0998232 | 21 SEAL-O-RING | 2 | |
| 1017397 | 22 BOLT-SOCKET HEAD (M12X1.75X50-MM) | 4 | |
| 1017401 | 23 BOLT-SOCKET HEAD (M10X1.5X20-MM) | 4 | |
| 1017402 | 24 BOLT-SOCKET HEAD (M12X1.75X30-MM) | 4 | |
| 1017404 | 25 BOLT-SOCKET HEAD (M10X1.5X30-MM) | 4 | |
| 1488323 | 26 CONNECTOR AS | 1 | |
| 2S4078 | SEAL-O-RING | 1 | |
| 5K9090 | SEAL-O-RING | 1 | |
| 6V9875 | CONNECTOR | 1 | |
| 1488330 | 27 CONNECTOR AS | 1 | |
| 5K9090 | SEAL-O-RING | 1 | |
| 8T0198 | CONNECTOR | 1 | |
| 7M8485 | SEAL-O-RING | 1 | |
| 1488347 | 28 ELBOW AS | 1 | |
| 3D2824 | SEAL-O-RING | 1 | |
| 6V9007 | ELBOW | 1 | |
| 6V9746 | SEAL-O-RING | 1 | |
| 1488352 | 29 ELBOW AS | 1 | |
| 5K9090 | SEAL-O-RING | 1 | |
| 6V9854 | ELBOW (SWIVEL) | 1 | |
| 1488355 | 30 ELBOW AS | 1 | |
| 5K9090 | SEAL-O-RING | 1 | |
| 6V9005 | ELBOW | 1 | |
| 7M8485 | SEAL-O-RING | 1 | |
| 1488411 | 31 PLUG AS | 1 | |
| 3K0360 | SEAL-O-RING | 1 | |
| 9S4185 | PLUG (3/4-16-THD) | 1 | |
| 1488429 | 32 TEE AS | 1 | |
| 5K9090 | SEAL-O-RING | 2 | |
| 6V9840 | TEE-SWIVEL | 1 | |
| 1536237 | 33 ELBOW AS | 1 | |
| 3D2824 | SEAL-O-RING | 1 | |
| 6V9004 | ELBOW | 1 | |
| 6V9746 | SEAL-O-RING | 1 | |
| 1644180 | 34 PLUG AS | 2 | |
| 7M8485 | SEAL-O-RING | 1 | |
| 9S4181 | PLUG (1-5/16-12-THD) | 1 | |
| 1734664 | 35 FLANGE | 1 | |
| 1P3702 | 36 SEAL-RECTANGULAR | 3 | |
| 1P3703 | 37 SEAL-RECTANGULAR | 4 | |
| 2802747 | 38 BOLT-SOCKET HEAD (M10X1.5X60-MM) | 4 | |
| 5K9090 | 39 SEAL-O-RING | 2 | |
| 5P7468 | 40 CLIP (SLOT) | 2 | |
| 5P7469 | 41 CLIP (TAB) | 2 | |
| 6V1874 | 42 GROMMET (31-MM ID)((31-MM ID)) | 2 | |
| 5P8444 | GROMMET (37-MM ID) | 2 | |
| 8T4121 | 43 WASHER-HARD (11X21X2.5-MM THK) | 8 | |
| 8T4136 | 44 BOLT (M10X1.5X25-MM) | 6 | |
| 8T4176 | 45 BOLT (M12X1.75X90-MM) | 4 | |
| 8T4196 | 46 BOLT (M10X1.5X35-MM) | 2 | |
| 8T4223 | 47 WASHER-HARD (13.5X25.5X3-MM THK) | 26 | |
| 8T4956 | 48 BOLT (M12X1.75X35-MM) | 6 | |
| 8T5092 | 49 BOLT (M12X1.75X150-MM) | 8 | |
| 8T4183 | 50 BOLT (M12X1.75X40-MM) | 8 |
