System And Components
260-8008 LINES GP-FRONT -SYSTEM 2, COMBINED FUNCTIONS/N A6F1-UP; A8F1-UP
Group No: 260-8008
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 7Y3729 | 1 FLANGE-SPECIAL | 1 | |
| 7Y3731 | 2 FLANGE | 1 | |
| 1021248 | 3 HOSE AS | 1 | |
| 1053477 | 4 BOLT-SOCKET HEAD (M10X1.5X45-MM) | 4 | |
| 1734664 | 5 FLANGE | 1 | |
| 1772653 | 6 VALVE GP-RELIEF (LINE) | 1 | |
| 2076222 | 7 BLOCK | 1 | |
| 2181139 | 8 BLOCK | 1 | |
| 2607872 | 9 SUPPORT AS | 1 | |
| 2608043 | 10 BLOCK | 1 | |
| 2660912 | 11 BRACKET | 1 | |
| 2660913 | 12 SUPPORT AS | 1 | |
| 3258865 | 13 SUPPORT AS | 1 | |
| 2661217 | 14 HOSE AS | 1 | |
| 3371424 | 15 SUPPORT AS | 1 | |
| 2661278 | 16 BLOCK | 1 | |
| 2661279 | 17 FLANGE | 2 | |
| 2661303 | 18 HOSE AS | 1 | |
| 3174712 | 19 HOSE AS | 1 | |
| 3148205 | 20 HOSE AS | 1 | |
| 5P8112 | 21 GROMMET | 1 | |
| 2751439 | 22 BLOCK | 1 | |
| 2751440 | 23 BLOCK | 1 | |
| 3371426 | 24 HOSE AS | 1 | |
| 2967067 | 25 SUPPORT AS | 1 | |
| 2967069 | 26 SUPPORT AS | 1 | |
| 2970370 | 27 VALVE GP-CHECK (1-WAY/2-WAY, CHECK) | 2 | |
| 0998232 | 28 SEAL-O-RING | 2 | |
| 1017397 | 29 BOLT-SOCKET HEAD (M12X1.75X50-MM) | 4 | |
| 1017401 | 30 BOLT-SOCKET HEAD (M10X1.5X20-MM) | 8 | |
| 1017402 | 31 BOLT-SOCKET HEAD (M12X1.75X30-MM) | 4 | |
| 1017404 | 32 BOLT-SOCKET HEAD (M10X1.5X30-MM) | 8 | |
| 1084282 | 33 BOLT-SOCKET HEAD (M10X1.5X100-MM) | 4 | |
| 1488323 | 34 CONNECTOR AS | 1 | |
| 2S4078 | SEAL-O-RING | 1 | |
| 5K9090 | SEAL-O-RING | 1 | |
| 6V9875 | CONNECTOR | 1 | |
| 1488330 | 35 CONNECTOR AS | 1 | |
| 5K9090 | SEAL-O-RING | 1 | |
| 8T0198 | CONNECTOR | 1 | |
| 7M8485 | SEAL-O-RING | 1 | |
| 1488339 | 36 CONNECTOR AS | 1 | |
| 6V8716 | CONNECTOR (STRAIGHT) | 1 | |
| 6V9746 | SEAL-O-RING | 1 | |
| 7M8485 | SEAL-O-RING | 1 | |
| 1488347 | 37 ELBOW AS | 1 | |
| 3D2824 | SEAL-O-RING | 1 | |
| 6V9007 | ELBOW | 1 | |
| 6V9746 | SEAL-O-RING | 1 | |
| 1488352 | 38 ELBOW AS | 1 | |
| 5K9090 | SEAL-O-RING | 1 | |
| 6V9854 | ELBOW (SWIVEL) | 1 | |
| 1488355 | 39 ELBOW AS | 1 | |
| 5K9090 | SEAL-O-RING | 1 | |
| 6V9005 | ELBOW | 1 | |
| 7M8485 | SEAL-O-RING | 1 | |
| 1488411 | 40 PLUG AS | 1 | |
| 3K0360 | SEAL-O-RING | 1 | |
| 9S4185 | PLUG (3/4-16-THD) | 1 | |
| 1488429 | 41 TEE AS | 1 | |
| 5K9090 | SEAL-O-RING | 2 | |
| 6V9840 | TEE-SWIVEL | 1 | |
| 1488449 | 42 TEE AS-SWIVEL | 1 | |
| 6V9746 | SEAL-O-RING | 2 | |
| 6V9839 | TEE-SWIVEL | 1 | |
| 1536237 | 43 ELBOW AS | 1 | |
| 3D2824 | SEAL-O-RING | 1 | |
| 6V9004 | ELBOW | 1 | |
| 6V9746 | SEAL-O-RING | 1 | |
| 1644180 | 44 PLUG AS | 1 | |
| 7M8485 | SEAL-O-RING | 1 | |
| 9S4181 | PLUG (1-5/16-12-THD) | 1 | |
| 1645606 | 46 CONNECTOR AS | 1 | |
| 3D2824 | SEAL-O-RING | 1 | |
| 6V9746 | SEAL-O-RING | 1 | |
| 8T0078 | CONNECTOR | 1 | |
| 1P3702 | 47 SEAL-RECTANGULAR | 6 | |
| 1P3703 | 48 SEAL-RECTANGULAR | 4 | |
| 2802747 | 49 BOLT-SOCKET HEAD (M10X1.5X60-MM) | 4 | |
| 5K9090 | 50 SEAL-O-RING | 2 | |
| 5P7468 | 51 CLIP (SLOT) | 2 | |
| 5P7469 | 52 CLIP (TAB) | 2 | |
| 6V1874 | 53 GROMMET (31-MM ID) | 2 | |
| 5P8444 | GROMMET (37-MM ID) | 2 | |
| 6V9746 | 54 SEAL-O-RING | 1 | |
| 8T4121 | 55 WASHER-HARD (11X21X2.5-MM THK) | 10 | |
| 8T4136 | 56 BOLT (M10X1.5X25-MM) | 6 | |
| 8T4176 | 57 BOLT (M12X1.75X90-MM) | 4 | |
| 8T4196 | 58 BOLT (M10X1.5X35-MM) | 2 | |
| 8T4223 | 59 WASHER-HARD (13.5X25.5X3-MM THK) | 27 | |
| 8T4956 | 60 BOLT (M12X1.75X35-MM) | 7 | |
| 8T5092 | 61 BOLT (M12X1.75X150-MM) | 8 | |
| 8T4183 | 62 BOLT (M12X1.75X40-MM) | 8 | |
| 8T4195 | 63 BOLT (M10X1.5X30-MM) | 2 | |
| 5P7466 | 64 CLIP (SLOT) | 1 | |
| 5P7467 | 65 CLIP (TAB) | 1 |
