System And Components
248-9853 LINES GP-RETURNS/N BZP1224-UP
Group No: 248-9853
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 4I9527 | 1 BAND-MARKER (GREEN, R3) | 2 | |
| 7K1181 | 2 STRAP-CABLE | 2 | |
| 2681621 | 3 FITTING AS | 1 | |
| 3D2824 | SEAL-O-RING | 1 | |
| 6V9746 | SEAL-O-RING | 1 | |
| 1241212 | FITTING | 1 | |
| 1653260 | 4 PIPE AS | 1 | |
| 1764770 | 5 HOSE AS | 1 | |
| 3075097 | 6 TEE AS | 1 | |
| 2M9780 | SEAL-O-RING | 1 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 6V8398 | SEAL-O-RING | 1 | |
| 3075098 | ADAPTER-TEE | 1 | |
| 2751361 | 7 HOSE AS | 1 | |
| 2927153 | 8 HOSE AS | 1 | |
| 1488327 | 9 CONNECTOR AS | 1 | |
| 3D2824 | SEAL-O-RING | 1 | |
| 6V8637 | CONNECTOR | 1 | |
| 6V9746 | SEAL-O-RING | 1 | |
| 1645608 | 10 CONNECTOR AS | 1 | |
| 3K0360 | SEAL-O-RING | 1 | |
| 6V8398 | SEAL-O-RING | 1 | |
| 8T1687 | CONNECTOR | 1 | |
| 1488347 | 11 ELBOW AS | 1 | |
| 3D2824 | SEAL-O-RING | 1 | |
| 6V9007 | ELBOW | 1 | |
| 6V9746 | SEAL-O-RING | 1 | |
| 1488354 | 12 ELBOW AS | 3 | |
| 3K0360 | SEAL-O-RING | 1 | |
| 6V8398 | SEAL-O-RING | 1 | |
| 6V9002 | ELBOW | 1 | |
| 1488358 | 13 ELBOW AS | 1 | |
| 2M9780 | SEAL-O-RING | 1 | |
| 6V8398 | SEAL-O-RING | 1 | |
| 6V8624 | ELBOW | 1 | |
| 1488363 | 14 ELBOW AS | 1 | |
| 3K0360 | SEAL-O-RING | 1 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 6V9876 | ELBOW | 1 | |
| 1488411 | 15 PLUG AS | 1 | |
| 3K0360 | SEAL-O-RING | 1 | |
| 9S4185 | PLUG (3/4-16-THD) | 1 | |
| 5P7464 | 17 CLIP (SLOT) | 1 | |
| 5P7465 | 18 CLIP (TAB) | 1 | |
| 6J2680 | 19 SEAL-O-RING | 1 | |
| 8T2920 | 21 GROMMET (27-MM ID) | 1 | |
| 8T4139 | 22 BOLT (M12X1.75X30-MM) | 1 | |
| 8T4223 | 23 WASHER-HARD (13.5X25.5X3-MM THK) | 5 | |
| 8T4956 | 24 BOLT (M12X1.75X35-MM) | 4 |
