System And Components
344-4312 LINES GP-BOOM -REACH, STICK LOAD CONTROLS/N FA21-10100
Group No: 344-4312
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 4I5997 | 1 HOSE AS | 1 | |
| 4I9523 | 2 BAND-MARKER (BLUE, L3) | 2 | |
| 1335813 | 3 BAND-MARKER (GRAY, P) | 2 | |
| 1538800 | 4 PLATE | 1 | |
| 3425487 | 5 PLATE | 1 | |
| 3444487 | 6 HOSE AS | 1 | |
| 3526772 | 7 CLIP AS | 3 | |
| 3543738 | 8 HOSE AS | 2 | |
| 4207255 | 9 TUBE AS | 1 | |
| 1488457 | 10 UNION AS (STRAIGHT) | 1 | |
| 6V8398 | SEAL-O-RING | 2 | |
| 6V8995 | UNION (STRAIGHT) | 1 | |
| 1495452 | 11 UNION AS (STRAIGHT) | 2 | |
| 6V8397 | SEAL-O-RING | 2 | |
| 6V8994 | UNION (STRAIGHT) | 1 | |
| 5Q4213 | 12 CLIP | 3 | |
| 6V8398 | 13 SEAL-O-RING | 2 | |
| 6V9168 | 14 NUT (11/16-16-THD) | 2 | |
| 6V9169 | 15 NUT (13/16-16-THD) | 1 | |
| 7K1181 | 16 STRAP-CABLE | 8 | |
| 8T4139 | 17 BOLT (M12X1.75X30-MM) | 6 | |
| 8T4223 | 18 WASHER-HARD (13.5X25.5X3-MM THK) | 8 | |
| 8T4648 | 19 BOLT (M12X1.75X70-MM) | 2 | |
| 8T5092 | 20 BOLT (M12X1.75X150-MM) | 2 |
