System And Components
278-6820 LINES GP-HYDRAULIC OIL COOLERS/N PBD1-UP
Group No: 278-6820
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 8T4956 | 1 BOLT (M12X1.75X35-MM) | 2 | |
| 8T6703 | 2 CLAMP-HOSE | 6 | |
| 3543759 | 3 PIPE AS | 1 | |
| 3543761 | 4 PIPE AS | 1 | |
| 2270290 | 5 SUPPORT AS | 1 | |
| 2270429 | 6 HOSE | 1 | |
| 2650072 | 7 TUBE AS | 1 | |
| 2650074 | 8 HOSE | 1 | |
| 2866423 | 9 TUBE AS | 1 | |
| 0964883 | 10 LOCKNUT (M10X1.5-THD) | 4 | |
| 1017402 | 11 BOLT-SOCKET HEAD (M12X1.75X30-MM) | 8 | |
| 1081781 | 12 BOLT-SOCKET HEAD (M12X1.75X35-MM) | 8 | |
| 4J0524 | 13 SEAL-O-RING | 4 | |
| 7Y5237 | 14 U-BOLT | 2 | |
| 8T4121 | 15 WASHER-HARD (11X21X2.5-MM THK) | 4 | |
| 8T4223 | 16 WASHER-HARD (13.5X25.5X3-MM THK) | 2 |
