System And Components
278-6821 LINES GP-HYDRAULICS/N KBZ226-UP
Group No: 278-6821
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 8T4223 | 1 WASHER-HARD (13.5X25.5X3-MM THK) | 16 | |
| 1132003 | 2 BOLT-SOCKET HEAD (M16X2X40-MM) | 4 | |
| 1140741 | 3 COVER | 1 | |
| 2181337 | 4 BLOCK | 1 | |
| 2181338 | 5 FLANGE | 1 | |
| 2181345 | 6 GROMMET | 1 | |
| 4609821 | 7 GROMMET | 1 | |
| 4641236 | 8 PLATE AS | 1 | |
| 9X6654 | 9 CLAMP-HOSE | 4 | |
| 2214700 | 10 HOSE AS | 1 | |
| 2214704 | 11 HOSE | 1 | |
| 2270329 | 12 BLOCK | 1 | |
| 2270330 | 13 HOSE AS | 1 | |
| 2448517 | 14 FLANGE | 2 | |
| 4641249 | 15 GROMMET | 1 | |
| 2852558 | 16 TUBE AS | 1 | |
| 1132001 | 17 BOLT-SOCKET HEAD (M12X1.75X25-MM) | 8 | |
| 1488407 | 18 PLUG AS | 1 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 9S4191 | PLUG (9/16-18-THD) | 1 | |
| 1645567 | 19 COUPLER AS-QUICK DISCONNECT (MALE) | 2 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 6V3965 | FITTING (QUICK DISCONNECT) | 1 | |
| 1P3703 | 20 SEAL-RECTANGULAR | 6 | |
| 1P3704 | 21 SEAL-RECTANGULAR | 2 | |
| 4J0522 | 22 SEAL-O-RING | 1 | |
| 5H8624 | 23 SEAL-O-RING | 2 | |
| 6V0400 | 25 FLANGE-HALF | 4 | |
| 6V0852 | 26 CAP-DUST | 2 | |
| 8T0348 | 27 BOLT-SOCKET HEAD (M16X2X50-MM) | 4 | |
| 8T4121 | 28 WASHER-HARD (11X21X2.5-MM THK) | 4 | |
| 8T4136 | 29 BOLT (M10X1.5X25-MM) | 4 | |
| 8T4176 | 30 BOLT (M12X1.75X90-MM) | 8 | |
| 8T4194 | 31 BOLT (M12X1.75X50-MM) | 8 | |
| 8T4195 | 32 BOLT (M10X1.5X30-MM) | 4 | |
| 4641239 | 33 PLATE AS | 1 |
