System And Components
358-9833 DOOR GP-ACCESSS/N SWF166-UP
Group No: 358-9833
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 2S1647 | 1 GROMMET | 1 | |
| 2188054 | 2 SPRING | 1 | |
| 2188055 | 3 HOOK AS | 1 | |
| 2188056 | 4 SPRING AS | 1 | |
| 2260294 | 5 LOCK AS | 1 | |
| 2260341 | 6 CAM | 1 | |
| 3019823 | 7 RING | 1 | |
| 3558031 | 8 DOOR AS-ACCESS | 1 | |
| 3589834 | 9 FENDER AS | 1 | |
| 3558163 | 10 LINER | 1 | |
| 0957930 | 11 SCREW-MACHINE (M4X0.7X6-MM) | 6 | |
| 0966166 | 12 WASHER-HARD (4.5X9X1-MM THK) | 6 | |
| 5C2890 | 13 NUT (M6X1-THD) | 2 | |
| 5P4116 | 14 WASHER-HARD (8.8X20.5X2-MM THK) | 2 | |
| 6V8823 | 15 WASHER-HARD (19.25X27X2-MM THK) | 2 | |
| 8T4138 | 16 BOLT (M6X1X20-MM) | 2 | |
| 8T4189 | 17 BOLT (M8X1.25X20-MM) | 2 | |
| 9X8256 | 18 WASHER (6.6X12X2-MM THK) | 4 |
