System And Components
305-4910 VALVE MECHANISM GPS/N GDC1-UP
Group No: 305-4910
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 2941684 | 1 VALVE-INLET | 12 | |
| 2941685 | 2 VALVE-EXHAUST | 12 | |
| 2941686 | 3 BASE-ROCKER ARM | 6 | |
| 2941687 | 4 BRIDGE-EXHAUST | 6 | |
| 5I7630 | 5 CAP | 12 | |
| 2941688 | 6 SPRING | 24 | |
| 2941689 | 7 SCREW | 12 | |
| 8T7964 | 8 NUT (M6X1-THD) | 12 | |
| 1992188 | 9 PIN-COTTER | 48 | |
| 1992189 | 10 SEAL-VALVE STEM | 24 | |
| 1992187 | 11 RETAINER | 24 | |
| 3054750 | 12 BRACKET | 6 | |
| 3054751 | 13 SPRING | 4 | |
| 2941693 | 14 PIPE | 1 | |
| 3054930 | 15 SHAFT AS-ROCKER ARM | 1 | |
| 0963741 | 15A CAP | 1 | |
| 3054929 | 16 ROCKER ARM AS | 6 | |
| 0913474 | 16A NUT (M8X1.25-THD) | 1 | |
| 0949525 | 16B SCREW | 1 | |
| 3054928 | 16C BUSHING | 1 | |
| 3054927 | 17 ROCKER ARM AS | 6 | |
| 0913474 | 17A NUT (M8X1.25-THD) | 1 | |
| 0949525 | 17B SCREW | 1 | |
| 3054928 | 17C BUSHING | 1 | |
| 2941698 | 18 WASHER | 4 | |
| 2941699 | 19 BOLT (M8X1.25X48.3-MM) | 6 | |
| 3054746 | 20 BOLT | 6 | |
| 2941786 | 21 RING | 4 | |
| 2941702 | 22 BOLT | 1 | |
| 3B4505 | 23 LOCKWASHER | 4 | |
| 3054747 | 24 WASHER | 4 |
