System And Components
204-6988 BATTERY & WIRING GPS/N D4M1-UP
Group No: 204-6988
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1343355 | 1 STRAP AS | 2 | |
| 2G8767 | 2 WASHER (10.5X60X3-MM THK) | 4 | |
| 3E8320 | 3 PLATE-INSTRUCTION (BATTERY) | 1 | |
| 1028703 | 4 PLATE-COVER | 2 | |
| 3V9830 | 5 TUBE | 1 | |
| 1074749 | 6 PLATE | 3 | |
| 6G2256 | 7 CLAMP | 7 | |
| 6G2263 | 8 SPACER (10.5X19X28.5-MM THK) | 6 | |
| 7N0718 | 9 SWITCH GP-DISCONNECT (BATTERY) | 1 | |
| 8R0768 | 10 ROD-RETAINING | 2 | |
| 1060800 | 11 CONNECTOR GP (REMOTE JUMP START, POSITIVE) | 1 | |
| 4D5243 | LOCKWASHER | 1 | |
| 9B9146 | NUT-SPECIAL (3/8-16-THD) | 1 | |
| 0625388 | LOCKNUT (1-11-1/2-THD) | 1 | |
| 2775777 | COVER-TERMINAL | 1 | |
| 1563618 | 12 CLAMP-HALF | 4 | |
| 1597466 | 13 ANGLE AS | 1 | |
| 1772215 | 14 STRAP-DUAL CLAMP | 5 | |
| 2349568 | 15 CABLE AS (BATTERY) | 1 | |
| 1598052 | CABLE-ELECTRICAL (00-GA)(117-CM) | ||
| 7N5274 | 15A COVER AS-TERMINAL (BLACK) | 1 | |
| 3S6051 | TERMINAL AS (POSITIVE) | 1 | |
| 1M6119 | BOLT (5/16-18X1.375-IN) | 1 | |
| 1M6120 | NUT (5/16-18-THD) | 1 | |
| 9G8909 | 15B COVER-TERMINAL (BLACK) | 1 | |
| 2349569 | 16 CABLE AS (BATTERY) | 1 | |
| 1598051 | CABLE-ELECTRICAL (00-GA)(159-CM) | ||
| 7T9987 | 16A COVER AS-TERMINAL (RED) | 1 | |
| 3S6051 | TERMINAL AS (POSITIVE) | 1 | |
| 1M6119 | BOLT (5/16-18X1.375-IN) | 1 | |
| 1M6120 | NUT (5/16-18-THD) | 1 | |
| 8N0869 | 16B COVER-TERMINAL (RED) | 1 | |
| 0350425 | RING-TERMINAL (000-GA, 3/8-IN SCREW) | 1 | |
| 2349567 | 17 CABLE AS (BATTERY) | 1 | |
| 1257876 | TUBE-HEAT SHRINK (17.78-MM DIA)(10-CM) | ||
| 1598052 | CABLE-ELECTRICAL (00-GA)(130-CM) | ||
| 5P2600 | RING-TERMINAL (000-GA, 1/2-IN SCREW) | 1 | |
| 0350425 | RING-TERMINAL (000-GA, 3/8-IN SCREW) | 1 | |
| 2096390 | 18 BRACKET | 1 | |
| 2349570 | 19 CABLE AS (BATTERY) | 1 | |
| 1257876 | TUBE-HEAT SHRINK (17.78-MM DIA)(5-CM) | ||
| 1598051 | CABLE-ELECTRICAL (00-GA)(197-CM) | ||
| 0350425 | RING-TERMINAL (000-GA, 3/8-IN SCREW) | 2 | |
| 8N0869 | COVER-TERMINAL (RED) | 1 | |
| 1152422 | 20 BATTERY GP (12-VOLT, MAINTENANCE FREE, WET) | 1 | |
| 1231373 | CAP AS-FILLER (7/8-9-THD) | 1 | |
| 2066419 | 21 CLAMP-HALF | 6 | |
| 1313540 | 22 LOCKNUT (M8X1.25-THD) | 2 | |
| 5P4116 | 23 WASHER-HARD (8.8X20.5X2-MM THK) | 2 | |
| 6V7687 | 24 LOCKNUT (M12X1.75-THD) | 2 | |
| 6V8801 | 25 NUT (3/8-16-THD) | 1 | |
| 7X2533 | 26 BOLT (M6X1X35-MM) | 6 | |
| 7X2537 | 27 BOLT (M8X1.25X35-MM) | 2 | |
| 7X7729 | 28 WASHER (11X25X3-MM THK) | 1 | |
| 7Y2292 | 29 WASHER (13X50X2-MM THK) | 1 | |
| 8T4121 | 30 WASHER-HARD (11X21X2.5-MM THK) | 1 | |
| 8T4137 | 31 BOLT (M10X1.5X20-MM) | 1 | |
| 8T4182 | 32 BOLT (M10X1.5X45-MM) | 4 | |
| 8T4194 | 33 BOLT (M12X1.75X50-MM) | 1 | |
| 8T4223 | 34 WASHER-HARD (13.5X25.5X3-MM THK) | 2 | |
| 8T6466 | 35 BOLT (M10X1.5X60-MM) | 1 | |
| 8T4185 | 36 BOLT (M10X1.5X50-MM) | 1 | |
| 7X0589 | 37 WASHER-HARD (12X28.5X5-MM THK) | 1 |
