System And Components
331-4074 DOOR GP-CABS/N JJM224-UP
Group No: 331-4074
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1018899 | 1 SCREW AS (M6X1.0X16-MM) | 2 | |
| 1018900 | 2 SCREW AS (M6X1X20-MM) | 2 | |
| 3276579 | 3 HANDLE-PULL | 1 | |
| 1566471 | 5 GLASS | 1 | |
| 1566598 | 6 HOOK | 1 | |
| 1566600 | 7 LOCK AS | 1 | |
| 1640514 | CLIP | 1 | |
| 1640519 | CLIP | 1 | |
| 1566643 | 8 COVER | 1 | |
| 1566645 | 9 HANDLE AS | 1 | |
| 2014391 | CLIP | 1 | |
| 1613639 | 10 HANDLE AS | 1 | |
| 1613650 | 11 COVER AS | 1 | |
| 1613663 | 12 SEAL AS | 1 | |
| 1519497 | CLIP | 45 | |
| 1613665 | 13 SEAL | 1 | |
| 2597354 | 14 COVER | 1 | |
| 1640515 | 15 JOINT | 1 | |
| 1677039 | 16 GROMMET | 1 | |
| 1858180 | 17 SCREW (M6X1X16-MM) | 3 | |
| 8T4224 | 18 WASHER-HARD (8.8X16X2-MM THK) | 2 | |
| 2250326 | 19 WINDOW GP-DOOR | 1 | |
| 0962622 | 20 SCREW-MACHINE (M4X0.7X8-MM) | 2 | |
| 3B4505 | 21 LOCKWASHER | 2 | |
| 1519461 | 22 SPACER | 4 | |
| 1566644 | 23 COVER | 1 | |
| 1785573 | 24 SPACER | 4 | |
| 1785574 | 25 SPACER | 3 | |
| 1892690 | 26 HANDLE | 1 | |
| 4I4286 | 27 KNOB | 1 | |
| 9X2042 | 28 SCREW-TRUSS HEAD (M6X1X12-MM) | 8 |
