System And Components
193-6632 LINES GP-STICK DRAINS/N JLC1-UP; JLD1-UP
Group No: 193-6632
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1880052 | 1 TUBE AS | 1 | |
| 1491738 | 2 CLIP | 2 | |
| 8T4223 | 3 WASHER-HARD (13.5X25.5X3-MM THK) | 4 | |
| 8T4139 | 4 BOLT (M12X1.75X30-MM) | 4 | |
| 1737864 | 5 HOSE AS | 1 | |
| 6V8398 | 6 SEAL-O-RING | 2 | |
| 1880044 | 7 SUPPORT AS | 1 | |
| 1880043 | 8 PLATE | 1 | |
| 8T4136 | 9 BOLT (M10X1.5X25-MM) | 2 | |
| 8T4121 | 10 WASHER-HARD (11X21X2.5-MM THK) | 2 | |
| 8T4185 | 11 BOLT (M10X1.5X50-MM) | 2 | |
| 6C6760 | 12 MANIFOLD | 1 | |
| 7X3164 | 13 ADAPTER-SWIVEL | 1 | |
| 3K0360 | 14 SEAL-O-RING | 1 |
