System And Components
524-8318 PUMP GP-MAIN HYDRAULIC -DOUBLE PISTONS/N DTG1-UP
Group No: 524-8318
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 5I8774 | 1 SETSCREW (M16X2X39-MM) | 2 | |
| 0985747 | 2 NUT (M16X2-THD) | 2 | |
| 8T1158 | 3 BOLT-SOCKET HEAD (M8X1.25X20-MM) | 8 | |
| 5413306 | 4 COVER | 2 | |
| 5413308 | 5 STOPPER | 2 | |
| 2324114 | 6 RING | 2 | |
| 2496659 | 7 SEAL-O-RING | 2 | |
| 5413309 | 8 PISTON | 2 | |
| 5413326 | 9 PIN AS | 2 | |
| 5I8772 | 10 EYEBOLT | 2 | |
| 2069295 | 11 SEAL-O-RING | 2 | |
| 0951784 | 12 RING-BACKUP | 2 | |
| 5413307 | 13 STOPPER | 2 | |
| 5413303 | 14 NUT (M16X2-THD) | 2 | |
| 5413300 | 15 SETSCREW (M16X2X55-MM) | 2 | |
| 2196915 | 16 BOLT (M16X2X95-MM) | 1 | |
| 8T0273 | 17 BOLT-SOCKET HEAD (M12X1.75X40-MM) | 12 | |
| 2959517 | 18 DOWEL | 2 | |
| 5413327 | 19 VALVE AS-SOLENOID (MAIN HYDRAULIC PUMP) | 1 | |
| 1697978 | 20 COVER | 1 | |
| 1053488 | 21 BOLT-SOCKET HEAD (M10X1.5X16-MM) | 2 | |
| 2469867 | 22 SEAL-O-RING | 1 | |
| 1105525 | 23 PLUG | 6 | |
| 2147568 | 24 SEAL-O-RING | 6 | |
| 5413316 | 25 SPRING | 18 | |
| 5413333 | 26 PISTON AS | 2 | |
| 5413318 | 27 PLATE-RETAINER | 2 | |
| 5413312 | 28 PLATE | 2 | |
| 5413328 | 29 SWASHPLATE AS | 2 | |
| 5413317 | 30 GUIDE-BALL | 2 | |
| 5413311 | 31 PLATE | 2 | |
| 5413310 | 32 BOLT-HEAD (M8X1.25X20-MM) | 8 | |
| 2478786 | 33 DOWEL | 2 | |
| 0950674 | 34 BOLT-SOCKET HEAD (M12X1.75X65-MM) | 10 | |
| 6V5203 | 35 RING-RETAINING | 2 | |
| 5413322 | 36 BEARING-ROLLER | 1 | |
| 3476530 | 37 SEAL-RECTANGULAR | 5 | |
| 7I8148 | 38 SPACER-BEARING | 2 | |
| 6V5204 | 39 RING-RETAINING | 2 | |
| 5413330 | 40 BODY AS-PUMP | 1 | |
| 5413331 | 41 BARREL AS | 1 | |
| 5413321 | 42 BEARING-NEEDLE | 2 | |
| 5413334 | 43 PUMP GP-GEAR | 1 | |
| 5413329 | 44 BLOCK AS | 1 | |
| 5413302 | 45 DOWEL | 2 | |
| 5413332 | 46 BARREL AS | 1 | |
| 5413304 | 47 GASKET | 1 | |
| 0965516 | 48 RING-RETAINING (EXTERNAL) | 1 | |
| 5413319 | 49 SPACER-BEARING | 1 | |
| 5413323 | 50 BEARING-ROLLER | 1 | |
| 5413301 | 51 DOWEL | 2 | |
| 5413305 | 52 GASKET | 1 | |
| 5413314 | 53 GEAR-DRIVE | 1 | |
| 2478717 | 54 SPACER (65X90X1-MM THK) | 2 | |
| 0950929 | 55 RING-RETAINING | 2 | |
| 2478726 | 56 COVER | 1 | |
| 5413325 | 57 SHAFT-DRIVE | 1 | |
| 2959695 | 58 SEAL-LIP TYPE | 1 | |
| 0950944 | 59 RING-RETAINING | 1 | |
| 2496657 | 60 SEAL-O-RING | 1 | |
| 5413313 | 61 GEAR-DRIVEN | 1 | |
| 5413324 | 62 SHAFT-DRIVEN | 1 | |
| 8T4240 | 63 RING-RETAINING | 1 | |
| 5413320 | 64 SPACER-BEARING | 1 | |
| 5413315 | 65 FLANGE | 1 | |
| 2478966 | 66 VALVE AS-CHECK | 4 | |
| 5H1472 | BALL | 1 | |
| 7I7448 | STOP | 1 | |
| 2069292 | 67 SEAL-O-RING | 4 | |
| 1899763 | 68 SEAL-O-RING | 2 | |
| 5413353 | 69 HEAD GP-PUMP | 2 |
