System And Components
416-5019 LINES GP-CONTROL -REARS/N EX71-UP; HSP1-UP
Group No: 416-5019
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1734672 | 1 VALVE GP-CHECK (OIL COOLER BYPASS) | 1 | |
| 1734816 | 2 SUPPORT AS | 1 | |
| 1875661 | 3 PIPE AS | 1 | |
| 1960807 | 4 PLATE | 1 | |
| 2048496 | 5 PLATE | 1 | |
| 2214872 | 6 HOSE | 1 | |
| 2607940 | 7 HOSE AS | 1 | |
| 2751473 | 8 SUPPORT AS | 1 | |
| 2827330 | 9 TUBE AS | 1 | |
| 2895362 | 10 TUBE AS | 1 | |
| 4190613 | 11 HOSE AS | 1 | |
| 4190616 | 12 HOSE AS | 1 | |
| 0964883 | 13 LOCKNUT (M10X1.5-THD) | 2 | |
| 1017402 | 14 BOLT-SOCKET HEAD (M12X1.75X30-MM) | 8 | |
| 1440367 | 15 CLAMP-HOSE | 2 | |
| 1488357 | 16 ELBOW AS | 1 | |
| 5K9090 | SEAL-O-RING | 1 | |
| 6V9008 | ELBOW (90-DEG) | 1 | |
| 7M8485 | SEAL-O-RING | 1 | |
| 1488364 | 17 ELBOW AS | 1 | |
| 3K0360 | SEAL-O-RING | 1 | |
| 6V8398 | SEAL-O-RING | 1 | |
| 6V8625 | ELBOW | 1 | |
| 1488408 | 18 PLUG AS | 1 | |
| 3D2824 | SEAL-O-RING | 1 | |
| 9S4183 | PLUG (1-1/16-12-THD) | 1 | |
| 1488411 | 19 PLUG AS | 1 | |
| 3K0360 | SEAL-O-RING | 1 | |
| 9S4185 | PLUG (3/4-16-THD) | 1 | |
| 1P3703 | 20 SEAL-RECTANGULAR | 4 | |
| 4J0524 | 21 SEAL-O-RING | 2 | |
| 4J0527 | 22 SEAL-O-RING | 2 | |
| 5P1076 | 23 WASHER-HARD (13.5X30X4-MM THK) | 1 | |
| 5P7468 | 24 CLIP (SLOT) | 3 | |
| 5P7469 | 25 CLIP (TAB) | 3 | |
| 5P8444 | 26 GROMMET (37-MM ID) | 1 | |
| 6V0400 | 27 FLANGE-HALF | 4 | |
| 7X2544 | 28 BOLT (M10X1.5X140-MM) | 4 | |
| 7Y5247 | 29 U-BOLT (M10X1.5-THD) | 1 | |
| 8T2525 | 30 GROMMET | 2 | |
| 8T4121 | 31 WASHER-HARD (11X21X2.5-MM THK) | 8 | |
| 8T4136 | 32 BOLT (M10X1.5X25-MM) | 2 | |
| 8T4139 | 33 BOLT (M12X1.75X30-MM) | 4 | |
| 8T4176 | 34 BOLT (M12X1.75X90-MM) | 4 | |
| 8T4183 | 35 BOLT (M12X1.75X40-MM) | 1 | |
| 8T4194 | 36 BOLT (M12X1.75X50-MM) | 8 | |
| 8T4223 | 37 WASHER-HARD (13.5X25.5X3-MM THK) | 17 | |
| 8T4910 | 38 BOLT (M12X1.75X60-MM) | 2 | |
| 8T4956 | 39 BOLT (M12X1.75X35-MM) | 2 |
