System And Components
255-1657 LINES GP-PILOT -ALT PATTERN CONTROL, 2-WAYS/N DFP1-UP; CJX1-UP
Group No: 255-1657 · Commonality
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 4I9521 | 1 BAND-MARKER (RED, L1) | 4 | |
| 4I9523 | 2 BAND-MARKER (BLUE, L3) | 4 | |
| 4I9525 | 3 BAND-MARKER (ORANGE, R1) | 4 | |
| 4I9527 | 4 BAND-MARKER (GREEN, R3) | 4 | |
| 5I8853 | 5 HOSE AS | 1 | |
| 7K1181 | 6 STRAP-CABLE | 7 | |
| 0874405 | 7 HOSE AS | 1 | |
| 0876583 | 8 HOSE AS | 2 | |
| 1087203 | 9 HOSE AS | 2 | |
| 1087387 | 10 HOSE AS | 2 | |
| 1185984 | 11 VALVE GP-PILOT (ALT PATTERN CONTROL, 2-WAY) | 1 | |
| 1241008 | 12 GUARD | 1 | |
| 1797433 | 13 SUPPORT | 1 | |
| 2551671 | 14 GROMMET | 1 | |
| 2551781 | 15 SUPPORT | 1 | |
| 1488378 | 17 ELBOW AS | 4 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 6V8724 | ELBOW | 1 | |
| 1503036 | 18 ELBOW AS | 4 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 8T1905 | ELBOW | 1 | |
| 8T4189 | 19 BOLT (M8X1.25X20-MM) | 2 | |
| 8T4192 | 20 BOLT (M12X1.75X25-MM) | 8 | |
| 8T4223 | 21 WASHER-HARD (13.5X25.5X3-MM THK) | 8 | |
| 8T4224 | 22 WASHER-HARD (8.8X16X2-MM THK) | 2 |
