System And Components
336-4582 HOOD & GUARD GPS/N YFW1-UP; DTZ1-UP
Group No: 336-4582
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3758750 | 1 LATCH AS | 1 | |
| 3758749 | 2 LATCH AS | 1 | |
| 4I0118 | 3 HOOK AS | 2 | |
| 4I0232 | 4 STRIKER | 2 | |
| 4I8019 | 5 SUPPORT | 3 | |
| 6I6033 | 6 STOP | 3 | |
| 1906880 | 7 SUPPORT AS | 3 | |
| 7Y2853 | 8 SPACER (13X38X5-MM THK) | 3 | |
| 0873908 | 9 SHIM (1-MM THK) | 2 | |
| 0873909 | 10 SHIM (2-MM THK) | 2 | |
| 1223979 | 11 BAND | 1 | |
| 1223980 | 12 ROD | 1 | |
| 1224120 | 13 ROD | 3 | |
| 1358573 | 14 BOLT AS | 76 | |
| 1358575 | 15 BOLT AS | 33 | |
| 1358577 | 16 BOLT AS | 3 | |
| 1358578 | 17 BOLT AS | 8 | |
| 1703016 | 18 SPACER (19X32X2-MM THK) | 6 | |
| 2034889 | 19 SPRING | 1 | |
| 2034890 | 20 SPRING | 1 | |
| 2125185 | 21 SUPPORT AS | 1 | |
| 2363304 | 22 SUPPORT AS | 1 | |
| 2363313 | 23 SUPPORT AS | 1 | |
| 2363328 | 24 SUPPORT | 1 | |
| 2363354 | 25 SUPPORT AS | 1 | |
| 2363363 | 26 COVER AS | 1 | |
| 2363367 | 27 SHEET AS | 1 | |
| 3727665 | 28 SHEET AS | 1 | |
| 2363387 | 29 SHEET AS-SOUND SUPPRESSION | 1 | |
| 2369540 | 30 HOOD GP-ENGINE | 1 | |
| 2378476 | 31 SUPPORT AS | 1 | |
| 2447912 | 32 SHEET AS-SOUND SUPPRESSION | 1 | |
| 2447917 | 33 SHEET AS-SOUND SUPPRESSION | 1 | |
| 2447922 | 34 SHEET AS-SOUND SUPPRESSION | 1 | |
| 2489312 | 35 SHEET AS | 1 | |
| 2505022 | 36 SUPPORT AS | 1 | |
| 2505024 | 37 SUPPORT AS | 1 | |
| 2561670 | 38 SUPPORT AS-ENCLOSURE | 1 | |
| 2561696 | 39 SUPPORT | 1 | |
| 2737678 | 40 SHEET AS-SOUND SUPPRESSION | 1 | |
| 2737802 | 41 SHEET AS-SOUND SUPPRESSION | 1 | |
| 2896898 | 42 DOOR GP-ACCESS (RADIATOR, LH) | 1 | |
| 2896903 | 43 DOOR GP-ACCESS (PUMP COMPARTMENT) | 1 | |
| 3301387 | 44 SUPPORT AS | 1 | |
| 3301388 | 45 SUPPORT AS | 1 | |
| 3301430 | 46 COVER AS-SOUND SUPPRESSION (FUEL, HYDRAULIC TANKS) | 1 | |
| 3301450 | 47 COVER AS | 1 | |
| 3420806 | 48 SUPPORT AS-BRACKET | 1 | |
| 3420808 | 49 SUPPORT AS-ENCLOSURE | 1 | |
| 3420812 | 50 SHEET AS-SOUND SUPPRESSION | 1 | |
| 3727668 | 51 COVER AS-SOUND SUPPRESSION | 1 | |
| 3421016 | 52 PLATE AS | 1 | |
| 3421017 | 53 SUPPORT AS-ENCLOSURE | 1 | |
| 3421019 | 54 SHEET AS-SOUND SUPPRESSION | 1 | |
| 3421022 | 55 SHEET AS | 1 | |
| 2622481 | LINER | 1 | |
| 3421091 | 56 SHEET AS-SOUND SUPPRESSION | 1 | |
| 3462768 | 57 DOOR GP-ACCESS (AIR CLEANER, BATTERY) | 1 | |
| 3B4618 | 58 PIN-COTTER | 3 | |
| 1053487 | 59 BOLT-SOCKET HEAD (M6X1X20-MM) | 6 | |
| 1146285 | 60 BAR | 2 | |
| 5C9553 | 61 BOLT (M6X1X16-MM) | 8 | |
| 5P1076 | 62 WASHER-HARD (13.5X30X4-MM THK) | 1 | |
| 5P4115 | 63 WASHER-HARD (7.2X19X2-MM THK) | 16 | |
| 7J5925 | 64 PIN-COTTER | 1 | |
| 7Y2854 | 65 SPACER (24X38X3-MM THK) | 3 | |
| 7Y2916 | 66 PIN-CLEVIS | 1 | |
| 8T4121 | 67 WASHER-HARD (11X21X2.5-MM THK) | 3 | |
| 8T4138 | 68 BOLT (M6X1X20-MM) | 10 | |
| 8T4189 | 69 BOLT (M8X1.25X20-MM) | 8 | |
| 8T4194 | 70 BOLT (M12X1.75X50-MM) | 2 | |
| 8T4223 | 71 WASHER-HARD (13.5X25.5X3-MM THK) | 4 | |
| 8T4224 | 72 WASHER-HARD (8.8X16X2-MM THK) | 8 | |
| 9X8256 | 73 WASHER (6.6X12X2-MM THK) | 8 |
