System And Components
416-5128 SUPPORT GP-HOODS/N PNW1494-UP
Group No: 416-5128 · Commonality
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 4I0118 | 1 HOOK AS | 2 | |
| 7Y2853 | 2 SPACER (13X38X5-MM THK) | 7 | |
| 1703016 | 3 SPACER (19X32X2-MM THK) | 14 | |
| 2447789 | 4 SPACER (19X38X3-MM THK) | 8 | |
| 2983112 | 5 HANDRAIL | 2 | |
| 3272884 | 6 BRACKET AS | 1 | |
| 3272886 | 7 STRIKER AS | 2 | |
| 3272889 | 8 SHEET AS | 1 | |
| 3301304 | 9 DOOR GP-ACCESS (AIR CLEANER, BATTERY) | 1 | |
| 3384008 | 10 DOOR GP-ACCESS (RADIATOR) | 1 | |
| 3384009 | 11 DOOR GP-ACCESS (PUMP COMPARTMENT) | 1 | |
| 3384068 | 12 SUPPORT AS | 1 | |
| 3384364 | LINER | 1 | |
| 3384093 | 13 SUPPORT | 1 | |
| 3384094 | 14 SUPPORT AS | 1 | |
| 3384111 | 15 SUPPORT AS | 1 | |
| 3384115 | 16 BRACKET AS | 3 | |
| 3384118 | 17 SUPPORT AS | 1 | |
| 3384184 | 18 BRACKET AS | 1 | |
| 3384202 | 19 SUPPORT AS | 1 | |
| 3384205 | LINER | 1 | |
| 3485409 | SEAL (10-DM) | ||
| 3384209 | 20 SHEET | 1 | |
| 3384210 | 21 SHEET AS-SOUND SUPPRESSION | 1 | |
| 3384215 | 22 SHEET AS-SOUND SUPPRESSION | 1 | |
| 3384220 | 23 SHEET AS-SOUND SUPPRESSION | 1 | |
| 3384233 | 24 SHEET AS | 1 | |
| 3384237 | 25 SHEET AS-SOUND SUPPRESSION | 1 | |
| 3384242 | 26 SHEET AS-SOUND SUPPRESSION | 1 | |
| 3384247 | 27 SHEET AS-SOUND SUPPRESSION | 1 | |
| 3384254 | 28 SHEET AS-SOUND SUPPRESSION | 1 | |
| 3384286 | 29 PLATE AS | 1 | |
| 3384288 | LINER | 1 | |
| 3384294 | 30 COVER AS-SOUND SUPPRESSION | 1 | |
| 3384328 | 31 COVER AS-SOUND SUPPRESSION | 1 | |
| 3384344 | 32 SHEET AS-SOUND SUPPRESSION | 1 | |
| 3397383 | 33 SUPPORT AS | 2 | |
| 3397384 | 34 SUPPORT AS | 2 | |
| 3432465 | 35 BUMPER | 4 | |
| 3432466 | 36 SHEET AS | 1 | |
| 3485409 | SEAL | 4 | |
| 3490020 | 37 SUPPORT AS | 1 | |
| 3504816 | 38 SHEET AS-SOUND SUPPRESSION | 1 | |
| 3384341 | LINER | 1 | |
| 3568961 | 39 SHEET AS-SOUND SUPPRESSION | 1 | |
| 3568963 | LINER | 1 | |
| 3597995 | 40 SHEET | 1 | |
| 3597996 | 41 SUPPORT AS | 1 | |
| 0543788 | WASHER (13.5X30X3-MM THK) | 2 | |
| 3719994 | 42 SUPPORT AS-ENCLOSURE | 1 | |
| 3719996 | 43 SUPPORT AS | 1 | |
| 3828630 | 44 ROLLER | 2 | |
| 3852295 | 45 SUPPORT AS | 1 | |
| 3852301 | 46 SHEET AS-SOUND SUPPRESSION | 1 | |
| 3852304 | 47 SHEET AS-SOUND SUPPRESSION | 1 | |
| 3852335 | 48 SPRING | 2 | |
| 3988112 | 49 SUPPORT AS | 1 | |
| 4165129 | 50 HOOD GP-ENGINE | 1 | |
| 3384337 | 51 COVER AS-SOUND SUPPRESSION | 1 | |
| 3384304 | 52 COVER AS | 1 | |
| 4309415 | 53 RETAINER | 2 | |
| 4310086 | 54 SUPPORT AS-ENCLOSURE | 1 | |
| 4310088 | 55 SHEET AS-SOUND SUPPRESSION | 1 | |
| 4310090 | 56 COVER AS-SOUND SUPPRESSION | 1 | |
| 4310092 | 57 COVER AS | 1 | |
| 4I7924 | WASHER (4.5X40X1.2-MM THK) | 5 | |
| 6P2216 | CAP (PUSH ON) | 5 | |
| 3384327 | SILENCER | 1 | |
| 4458141 | 58 SUPPORT AS-SOUND SUPPRESSION | 1 | |
| 1358573 | 59 BOLT AS | 51 | |
| 1358575 | 60 BOLT AS | 105 | |
| 1358577 | 61 BOLT AS | 2 | |
| 5P0372 | 62 LOCK PIN | 1 | |
| 5P1076 | 63 WASHER-HARD (13.5X30X4-MM THK) | 1 | |
| 5P4116 | 64 WASHER-HARD (8.8X20.5X2-MM THK) | 4 | |
| 7Y2854 | 65 SPACER (24X38X3-MM THK) | 7 | |
| 7Y2916 | 66 PIN-CLEVIS | 1 | |
| 8T4121 | 67 WASHER-HARD (11X21X2.5-MM THK) | 17 | |
| 8T4133 | 68 NUT (M10X1.5-THD) | 4 | |
| 8T4136 | 69 BOLT (M10X1.5X25-MM) | 4 | |
| 8T4137 | 70 BOLT (M10X1.5X20-MM) | 9 | |
| 8T4189 | 71 BOLT (M8X1.25X20-MM) | 8 | |
| 8T4196 | 72 BOLT (M10X1.5X35-MM) | 4 | |
| 8T4223 | 73 WASHER-HARD (13.5X25.5X3-MM THK) | 4 | |
| 8T4224 | 74 WASHER-HARD (8.8X16X2-MM THK) | 4 | |
| 8T6868 | 75 BOLT (M12X1.75X80-MM) | 2 | |
| 3384336 | 76 SHEET | 1 |
