System And Components
516-8488 SENSOR & MTG GP-POSITION -GRADE CONTROL, BUCKETS/N GDY1-UP
Group No: 516-8488
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 8T4196 | 1 BOLT (M10X1.5X35-MM) | 1 | |
| 8T4189 | 2 BOLT (M8X1.25X20-MM) | 3 | |
| 3S2093 | 3 STRAP-CABLE | 20 | |
| 8T4222 | 4 WASHER-PLATED (11X32X2.5-MM THK) | 3 | |
| 8T4224 | 5 WASHER-HARD (8.8X16X2-MM THK) | 3 | |
| 8T7934 | 6 WASHER-HARD (11X21X5-MM THK) | 1 | |
| 1364192 | 7 BOLT (M6X1X35-MM) | 5 | |
| 4784873 | 8 SENSOR-POSITION (BUCKET)(TARGET) | 1 | |
| 4784876 | 9 SENSOR GP-POSITION (BUCKET)(ROTARY) | 1 | |
| 2304014 | RECEPTACLE AS-CONNECTOR (3-PIN) | 1 | |
| 5019243 | 10 COVER AS | 1 | |
| 7T1099 | LINK | 2 | |
| 8T4121 | 11 WASHER-HARD (11X21X2.5-MM THK) | 3 | |
| 8T4137 | 12 BOLT (M10X1.5X20-MM) | 3 | |
| 9X8256 | 13 WASHER (6.6X12X2-MM THK) | 5 | |
| 3E6600 | 14 SEAL (1.5-CM EACH) | ||
| 5754554 | 15 PLATE | 3 | |
| 7X7729 | 16 WASHER (11X25X3-MM THK) | 1 |
