System And Components
230-0486 LINES GP-AUXILIARY HYDRAULIC -REACH BOOM, HIGH PRESSURES/N DTG1-UP
Group No: 230-0486
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1136677 | 1 HOSE AS | 1 | |
| 1512494 | 2 BAR | 4 | |
| 1538798 | 3 PLATE | 2 | |
| 1737916 | 4 CLAMP-HALF | 8 | |
| 1879845 | 5 TUBE AS | 1 | |
| 1879846 | 6 TUBE AS | 1 | |
| 2300494 | 7 SUPPORT AS | 2 | |
| 2373116 | 8 TUBE AS | 1 | |
| 2373117 | 9 TUBE AS | 1 | |
| 2825760 | 10 HOSE AS | 1 | |
| 1P3703 | 11 SEAL-RECTANGULAR | 3 | |
| 1P3704 | 12 SEAL-RECTANGULAR | 2 | |
| 1P3705 | 13 SEAL-RECTANGULAR | 1 | |
| 1P5767 | 14 FLANGE-HALF | 4 | |
| 6V0400 | 15 FLANGE-HALF | 4 | |
| 7Y4538 | 16 CLAMP-HALF | 8 | |
| 8T4139 | 17 BOLT (M12X1.75X30-MM) | 16 | |
| 8T4183 | 18 BOLT (M12X1.75X40-MM) | 4 | |
| 8T4184 | 19 BOLT (M12X1.75X45-MM) | 16 | |
| 8T4194 | 20 BOLT (M12X1.75X50-MM) | 8 | |
| 8T4223 | 21 WASHER-HARD (13.5X25.5X3-MM THK) | 44 | |
| 8T6868 | 22 BOLT (M12X1.75X80-MM) | 8 |
