System And Components
230-0490 LINES GP-AUXILIARY HYDRAULIC -MASS BOOM, HIGH PRESSURES/N DTG1-UP
Group No: 230-0490
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1512494 | 1 BAR | 4 | |
| 8T4139 | 2 BOLT (M12X1.75X30-MM) | 16 | |
| 8T4183 | 3 BOLT (M12X1.75X40-MM) | 4 | |
| 8T4184 | 4 BOLT (M12X1.75X45-MM) | 16 | |
| 8T4194 | 5 BOLT (M12X1.75X50-MM) | 8 | |
| 8T6868 | 6 BOLT (M12X1.75X80-MM) | 8 | |
| 1737916 | 7 CLAMP-HALF | 8 | |
| 7Y4538 | 8 CLAMP-HALF | 8 | |
| 1P5767 | 9 FLANGE-HALF | 4 | |
| 6V0400 | 10 FLANGE-HALF | 4 | |
| 1136677 | 11 HOSE AS | 1 | |
| 2825760 | 12 HOSE AS | 1 | |
| 1538798 | 13 PLATE | 2 | |
| 1P3703 | 14 SEAL-RECTANGULAR | 3 | |
| 1P3704 | 15 SEAL-RECTANGULAR | 2 | |
| 1P3705 | 16 SEAL-RECTANGULAR | 1 | |
| 2300494 | 17 SUPPORT AS | 2 | |
| 1972348 | 18 TUBE AS | 1 | |
| 1972349 | 19 TUBE AS | 1 | |
| 2479310 | 20 TUBE AS | 1 | |
| 2479311 | 21 TUBE AS | 1 | |
| 8T4223 | 22 WASHER-HARD (13.5X25.5X3-MM THK) | 44 |
