System And Components
227-0551 LINES GP-BOOM -1-PIECE SHORT BOOMS/N DTG1-UP
Group No: 227-0551
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 4I1674 | 1 CLIP | 5 | |
| 7Y4868 | 2 CLIP | 8 | |
| 1876993 | 3 CLIP | 5 | |
| 2023763 | 4 CLIP AS | 1 | |
| 2023764 | 5 CLIP AS | 1 | |
| 2023875 | 6 TUBE AS | 1 | |
| 2023876 | 7 TUBE AS | 1 | |
| 2023877 | 8 TUBE AS | 1 | |
| 2023878 | 9 TUBE AS | 1 | |
| 2363005 | 10 HOSE AS | 1 | |
| 2363009 | 11 HOSE AS | 1 | |
| 2967419 | 12 TUBE AS | 1 | |
| 2967420 | 13 TUBE AS | 1 | |
| 1P3703 | 14 SEAL-RECTANGULAR | 3 | |
| 1P3704 | 15 SEAL-RECTANGULAR | 1 | |
| 1P5767 | 16 FLANGE-HALF | 2 | |
| 6V0400 | 17 FLANGE-HALF | 6 | |
| 6V9746 | 18 SEAL-O-RING | 6 | |
| 8T4139 | 19 BOLT (M12X1.75X30-MM) | 16 | |
| 8T4184 | 20 BOLT (M12X1.75X45-MM) | 10 | |
| 8T4194 | 21 BOLT (M12X1.75X50-MM) | 8 | |
| 8T4223 | 22 WASHER-HARD (13.5X25.5X3-MM THK) | 36 | |
| 8T6868 | 23 BOLT (M12X1.75X80-MM) | 2 | |
| 9F2167 | 24 SCREW-PURGE (3/8-24X1.164-IN) | 2 | |
| 6H3615 | 25 PLUG-PROTECTION | 2 |
