System And Components
242-6037 FRAME GP-UPPERS/N JLC1-UP
Group No: 242-6037
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 4I0575 | 1 SHIM (1-MM THK) | 2 | |
| 4I0577 | 2 SHIM (2-MM THK) | 1 | |
| 0930364 | 3 SPACER (103X140X12-MM THK) | 2 | |
| 1120885 | 4 PAD AS-RESILIENT | 2 | |
| 1543637 | 5 PIN | 1 | |
| 1602168 | 6 SHIM (2-MM THK) | 6 | |
| 1661489 | 7 SHIM (2-MM THK) | 2 | |
| 1785360 | 8 BEARING | 4 | |
| 1786175 | 9 PIN | 2 | |
| 2502404 | 10 PIN AS | 1 | |
| 1865663 | 11 PIN AS | 2 | |
| 1877661 | 12 BUMPER AS | 1 | |
| 2012771 | 13 WASHER (26X90X8-MM THK) | 1 | |
| 2034426 | 14 SHIM (2-MM THK) | 8 | |
| 2169350 | 15 SUPPORT AS | 1 | |
| 2175071 | 16 PIN | 1 | |
| 2181498 | 17 CYLINDER GP-CAB TILT | 1 | |
| 2097536 | BEARING | 4 | |
| 2100371 | KIT-SEAL (CAB TILT CYLINDER) | 1 | |
| 2426038 | 18 FRAME AS-UPPER | 1 | |
| 0964882 | 19 LOCKNUT (M8X1.25-THD) | 4 | |
| 0966467 | 20 WASHER (22X60X8-MM THK) | 2 | |
| 1332428 | 21 SHIM (0.5-MM THK) | 1 | |
| 1661488 | 22 SHIM (2-MM THK) | 4 | |
| 1805932 | 23 BOLT (M20X2.5X80-MM) | 2 | |
| 5C7261 | 24 NUT (M8X1.25-THD) | 4 | |
| 7X2572 | 25 BOLT (M24X3X35-MM) | 1 | |
| 8T4121 | 26 WASHER-HARD (11X21X2.5-MM THK) | 6 | |
| 8T4123 | 27 WASHER (22X35X3.5-MM THK) | 2 | |
| 8T4131 | 28 NUT (M20X2.5-THD) | 2 | |
| 8T4133 | 29 NUT (M10X1.5-THD) | 2 | |
| 8T4136 | 30 BOLT (M10X1.5X25-MM) | 4 | |
| 8T4167 | 31 WASHER-HARD (26X44X4-MM THK) | 1 | |
| 8T4182 | 32 BOLT (M10X1.5X45-MM) | 2 | |
| 8T4191 | 33 BOLT (M10X1.5X16-MM) | 1 | |
| 8T4780 | 34 BOLT (M20X2.5X30-MM) | 2 | |
| 8T6870 | 35 BOLT (M8X1.25X70-MM) | 4 | |
| 0930090 | 36 SHIM (1-MM THK) | 4 | |
| 1332427 | 37 SHIM (0.5-MM THK) | 2 |
