System And Components
179-7799 LINES GP-FRONTS/N JLC303-UP; JLD343-UP
Group No: 179-7799
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 7Y7904 | 1 HOSE AS | 4 | |
| 1017403 | 2 BOLT-SOCKET HEAD (M10X1.5X80-MM) | 2 | |
| 1053483 | 3 BOLT-SOCKET HEAD (M10X1.5X70-MM) | 2 | |
| 1216460 | 4 SUPPORT AS | 1 | |
| 1335828 | 5 SUPPORT AS | 1 | |
| 2649963 | 6 VALVE GP-LOAD CONTROL (BOOM CYLINDER) | 1 | |
| 2649962 | 7 VALVE GP-LOAD CONTROL (STICK CYLINDER) | 1 | |
| 1849575 | 8 TUBE AS | 1 | |
| 1849576 | 9 TUBE AS | 1 | |
| 1875935 | 10 BLOCK | 1 | |
| 1876027 | 11 HOSE AS | 1 | |
| 1940174 | 12 HOSE GP-HYDRAULIC | 1 | |
| 1940177 | 13 HOSE GP-HYDRAULIC (CONTROL VALVE, STICK) | 1 | |
| 1940180 | 14 HOSE GP-HYDRAULIC | 1 | |
| 1991286 | 15 BOLT-SOCKET HEAD (M10X1.5X150-MM) | 6 | |
| 1991620 | 16 HOSE AS | 2 | |
| 2024038 | 17 HOSE AS | 1 | |
| 2181127 | 18 TUBE AS | 1 | |
| 1017397 | 19 BOLT-SOCKET HEAD (M12X1.75X50-MM) | 4 | |
| 1017404 | 20 BOLT-SOCKET HEAD (M10X1.5X30-MM) | 30 | |
| 1087550 | 21 CLIP | 1 | |
| 1370856 | 22 TUBE AS | 1 | |
| 1488335 | 23 CONNECTOR AS | 1 | |
| 5K9090 | SEAL-O-RING | 1 | |
| 6V8635 | CONNECTOR | 1 | |
| 7M8485 | SEAL-O-RING | 1 | |
| 1644180 | 24 PLUG AS | 1 | |
| 9S4181 | PLUG (1-5/16-12-THD) | 1 | |
| 7M8485 | SEAL-O-RING | 1 | |
| 1P3703 | 25 SEAL-RECTANGULAR | 6 | |
| 1P3704 | 26 SEAL-RECTANGULAR | 3 | |
| 1P5767 | 27 FLANGE-HALF | 4 | |
| 4I1674 | 28 CLIP | 2 | |
| 4J5267 | 29 SEAL-O-RING | 5 | |
| 4J5268 | 30 SEAL-O-RING | 1 | |
| 6V0400 | 31 FLANGE-HALF | 2 | |
| 6V9746 | 32 SEAL-O-RING | 6 | |
| 7Y3721 | 33 TUBE AS | 1 | |
| 8T4139 | 34 BOLT (M12X1.75X30-MM) | 4 | |
| 8T4184 | 35 BOLT (M12X1.75X45-MM) | 4 | |
| 1017398 | 36 BOLT-SOCKET HEAD (M10X1.5X40-MM) | 4 | |
| 8T4223 | 37 WASHER-HARD (13.5X25.5X3-MM THK) | 22 | |
| 8T4910 | 38 BOLT (M12X1.75X60-MM) | 6 | |
| 9F2167 | 39 SCREW-PURGE (3/8-24X1.164-IN) | 1 | |
| 8T4194 | 40 BOLT (M12X1.75X50-MM) | 4 |
