System And Components
184-9492 LINES GP-FRONT -SYSTEM 14, COMBINED FUNCTIONS/N JLC1-UP; JLD1-UP
Group No: 184-9492
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1053479 | 1 BOLT-SOCKET HEAD (M10X1.5X90-MM) | 4 | |
| 1427781 | 2 BLOCK | 1 | |
| 2218859 | 3 SENSOR AS-PRESSURE (BOOM CYLINDER) | 1 | |
| 3E3371 | WEDGE-RECEPTACLE LOCK (3-PIN) | 1 | |
| 3K0360 | SEAL-O-RING | 1 | |
| 9X3401 | PIN-CONNECTOR (16-GA TO 18-GA) | 3 | |
| 1261767 | PIN-CONNECTOR (14-GA TO 16-GA) | 3 | |
| 1710596 | RECEPTACLE AS-CONNECTOR (3-PIN) | 1 | |
| 2019367 | 4 VALVE GP-SOLENOID (1-WAY/2-WAY FLOW) | 3 | |
| 1875949 | 5 HOSE AS | 1 | |
| 1876040 | 6 SUPPORT AS | 1 | |
| 1876719 | 7 BLOCK | 1 | |
| 1876720 | 8 BLOCK | 1 | |
| 1876833 | 9 HOSE AS | 1 | |
| 1876836 | 10 HOSE AS | 1 | |
| 1876843 | 11 HOSE AS | 1 | |
| 1876850 | 12 PLATE | 1 | |
| 1876851 | 13 PLATE | 1 | |
| 1960826 | 14 BLOCK | 1 | |
| 1960827 | 15 PLATE | 1 | |
| 1991762 | 16 TUBE AS | 1 | |
| 1991763 | 17 HOSE AS | 1 | |
| 1991773 | 18 ELBOW | 1 | |
| 1991828 | 19 HOSE AS | 1 | |
| 1991918 | 20 FLANGE | 1 | |
| 2023751 | 21 PLATE | 2 | |
| 2023987 | 22 PLATE | 2 | |
| 2023988 | 23 SUPPORT AS | 1 | |
| 2048184 | 24 PLATE AS | 1 | |
| 2076324 | 25 HOSE AS | 1 | |
| 2076430 | 26 TUBE AS | 1 | |
| 0998232 | 27 SEAL-O-RING | 2 | |
| 1017404 | 28 BOLT-SOCKET HEAD (M10X1.5X30-MM) | 16 | |
| 1053485 | 29 BOLT-SOCKET HEAD (M12X1.75X60-MM) | 4 | |
| 1084282 | 30 BOLT-SOCKET HEAD (M10X1.5X100-MM) | 4 | |
| 1488317 | 31 CONNECTOR AS | 1 | |
| 3D2824 | SEAL-O-RING | 1 | |
| 5K9090 | SEAL-O-RING | 1 | |
| 6V8714 | CONNECTOR | 1 | |
| 1488335 | 32 CONNECTOR AS | 4 | |
| 5K9090 | SEAL-O-RING | 1 | |
| 6V8635 | CONNECTOR | 1 | |
| 7M8485 | SEAL-O-RING | 1 | |
| 1488347 | 33 ELBOW AS | 1 | |
| 3D2824 | SEAL-O-RING | 1 | |
| 6V9746 | SEAL-O-RING | 1 | |
| 1488362 | 34 ELBOW AS | 1 | |
| 3D2824 | SEAL-O-RING | 1 | |
| 5K9090 | SEAL-O-RING | 1 | |
| 8T6684 | ELBOW (90-DEG) | 1 | |
| 1488387 | 35 ELBOW AS | 1 | |
| 6V8400 | SEAL-O-RING | 1 | |
| 6V9855 | ELBOW | 1 | |
| 1644180 | 36 PLUG AS | 1 | |
| 7M8485 | SEAL-O-RING | 1 | |
| 9S4181 | PLUG (1-5/16-12-THD) | 1 | |
| 1659629 | 37 VALVE GP-SOLENOID & RELIEF (LINE) | 2 | |
| 1P3702 | 38 SEAL-RECTANGULAR | 1 | |
| 1P3703 | 39 SEAL-RECTANGULAR | 6 | |
| 1P3704 | 40 SEAL-RECTANGULAR | 3 | |
| 1P4578 | 41 FLANGE-HALF | 2 | |
| 2048182 | 42 GROMMET | 2 | |
| 2048183 | 43 PLATE | 1 | |
| 2S4078 | 44 SEAL-O-RING | 1 | |
| 4J0522 | 45 SEAL-O-RING | 1 | |
| 4J5267 | 46 SEAL-O-RING | 1 | |
| 5K9090 | 47 SEAL-O-RING | 3 | |
| 5P7468 | 48 CLIP (SLOT) | 1 | |
| 5P7469 | 49 CLIP (TAB) | 1 | |
| 6V0545 | 50 GROMMET | 1 | |
| 6V8400 | 51 SEAL-O-RING | 1 | |
| 6V9746 | 52 SEAL-O-RING | 3 | |
| 7Y3729 | 53 FLANGE-SPECIAL | 1 | |
| 7Y3730 | 54 FLANGE-SPECIAL | 1 | |
| 7Y3731 | 55 FLANGE | 1 | |
| 8T4121 | 56 WASHER-HARD (11X21X2.5-MM THK) | 7 | |
| 8T4139 | 57 BOLT (M12X1.75X30-MM) | 8 | |
| 8T4176 | 58 BOLT (M12X1.75X90-MM) | 8 | |
| 8T4183 | 59 BOLT (M12X1.75X40-MM) | 2 | |
| 8T4186 | 60 BOLT (M10X1.5X40-MM) | 4 | |
| 8T4192 | 61 BOLT (M12X1.75X25-MM) | 1 | |
| 8T4194 | 62 BOLT (M12X1.75X50-MM) | 1 | |
| 8T4223 | 63 WASHER-HARD (13.5X25.5X3-MM THK) | 48 | |
| 8T4910 | 64 BOLT (M12X1.75X60-MM) | 4 | |
| 8T4956 | 65 BOLT (M12X1.75X35-MM) | 12 | |
| 8T5005 | 66 BOLT (M10X1.5X70-MM) | 3 | |
| 8T5092 | 67 BOLT (M12X1.75X150-MM) | 8 | |
| 8T5412 | 68 BOLT (M12X1.75X140-MM) | 4 |
