System And Components
218-0994 LINES GP-RETURN -BOOM FLOATS/N JLC1-UP; JLD1-UP
Group No: 218-0994
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1053477 | 1 BOLT-SOCKET HEAD (M10X1.5X45-MM) | 4 | |
| 1850488 | 2 BLOCK | 1 | |
| 1875989 | 3 BLOCK | 1 | |
| 1939945 | 4 SUPPORT AS | 1 | |
| 1939953 | 5 HOSE AS | 1 | |
| 1960910 | 6 HOSE AS | 1 | |
| 1992012 | 7 PLATE | 1 | |
| 2029002 | 8 SWITCH AS-PRESSURE (BOOM RETURN) | 1 | |
| 1028802 | KIT-RECEPTACLE (2-PIN) | 1 | |
| 1863735 | PIN-CONNECTOR (16-GA TO 18-GA) | 1 | |
| 3E3365 | WEDGE-RECEPTACLE LOCK (2-PIN) | 1 | |
| 2078494 | 9 HOSE AS | 1 | |
| 2181125 | 10 BLOCK | 1 | |
| 2181126 | 11 BLOCK | 1 | |
| 2181130 | 12 BLOCK | 1 | |
| 2181145 | 13 TUBE AS | 1 | |
| 2181146 | 14 TUBE AS | 1 | |
| 2181147 | 15 TUBE AS | 1 | |
| 2181148 | 16 TUBE AS | 1 | |
| 2181161 | 17 HOSE AS | 1 | |
| 2181164 | 18 HOSE AS | 1 | |
| 2236747 | 19 SUPPORT AS | 1 | |
| 2255807 | 20 VALVE GP-CHECK (BOOM FLOAT, ROD END) | 1 | |
| 2270322 | 21 HOSE AS | 1 | |
| 2270337 | 22 HOSE AS | 1 | |
| 1081782 | 23 BOLT-SOCKET HEAD (M12X1.75X90-MM) | 8 | |
| 1488322 | 24 CONNECTOR AS | 1 | |
| 2M9780 | SEAL-O-RING | 1 | |
| 6V8640 | CONNECTOR | 1 | |
| 6V9746 | SEAL-O-RING | 1 | |
| 1488355 | 25 ELBOW AS | 1 | |
| 5K9090 | SEAL-O-RING | 1 | |
| 7M8485 | SEAL-O-RING | 1 | |
| 6V9005 | ELBOW | 1 | |
| 1488357 | 26 ELBOW AS | 3 | |
| 5K9090 | SEAL-O-RING | 1 | |
| 7M8485 | SEAL-O-RING | 1 | |
| 6V9008 | ELBOW (90-DEG) | 1 | |
| 1488372 | 27 ELBOW AS | 1 | |
| 2M9780 | SEAL-O-RING | 1 | |
| 6V8398 | SEAL-O-RING | 1 | |
| 6V8721 | ELBOW | 1 | |
| 1488392 | 28 ELBOW AS | 2 | |
| 6V9746 | SEAL-O-RING | 1 | |
| 6V9853 | ELBOW | 1 | |
| 1488411 | 29 PLUG AS | 4 | |
| 3K0360 | SEAL-O-RING | 1 | |
| 9S4185 | PLUG (3/4-16-THD) | 1 | |
| 1646858 | 30 TEE AS | 1 | |
| 5K9090 | SEAL-O-RING | 2 | |
| 6V8778 | TEE-FACE SEAL | 1 | |
| 7M8485 | SEAL-O-RING | 1 | |
| 1P3703 | 31 SEAL-RECTANGULAR | 5 | |
| 1P3704 | 32 SEAL-RECTANGULAR | 7 | |
| 2125586 | 33 SUPPORT | 1 | |
| 2125602 | 34 TUBE AS | 1 | |
| 2125603 | 35 TUBE AS | 1 | |
| 3J1907 | 36 SEAL-O-RING | 1 | |
| 4I1674 | 37 CLIP | 2 | |
| 4J5268 | 38 SEAL-O-RING | 1 | |
| 5K9090 | 39 SEAL-O-RING | 2 | |
| 6V9746 | 40 SEAL-O-RING | 5 | |
| 7K1181 | 41 STRAP-CABLE | 2 | |
| 7M8485 | 42 SEAL-O-RING | 1 | |
| 8T4139 | 43 BOLT (M12X1.75X30-MM) | 14 | |
| 8T4192 | 44 BOLT (M12X1.75X25-MM) | 2 | |
| 8T4223 | 45 WASHER-HARD (13.5X25.5X3-MM THK) | 32 | |
| 8T4910 | 46 BOLT (M12X1.75X60-MM) | 8 | |
| 8T4956 | 47 BOLT (M12X1.75X35-MM) | 8 | |
| 8T6466 | 48 BOLT (M10X1.5X60-MM) | 4 | |
| 8T6868 | 49 BOLT (M12X1.75X80-MM) | 8 | |
| 2255807 | 50 VALVE GP-CHECK (BOOM FLOAT, HEAD END) | 1 |
