System And Components
205-3943 LINES GP-STICK -C-FAMILYS/N JLC1-UP; JLD1-UP
Group No: 205-3943
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 8T4136 | 1 BOLT (M10X1.5X25-MM) | 4 | |
| 2490013 | 2 HOSE AS | 2 | |
| 2053948 | 3 LINK AS | 1 | |
| 2491096 | 4 TUBE AS | 2 | |
| 8T4121 | 5 WASHER-HARD (11X21X2.5-MM THK) | 4 | |
| 2413136 | 6 HOSE AS | 2 | |
| 6V8398 | 7 SEAL-O-RING | 4 | |
| 2H2221 | 8 CLAMP | 4 | |
| 8S3215 | 9 CLAMP-TUBE | 4 | |
| 1488377 | 10 ELBOW AS | 2 | |
| 6V8397 | SEAL-O-RING | 2 | |
| 6V8980 | ELBOW | 1 | |
| 6V9168 | 11 NUT (11/16-16-THD) | 2 | |
| 6V9829 | 12 CAP (ORFS) | 2 | |
| 2053949 | 13 LINK AS | 1 | |
| 1665495 | 14 CHANNEL | 1 | |
| 9X2199 | 15 BOLT (M30X3.5X50-MM) | 2 | |
| 8X7933 | 16 SPACER (33X57X14-MM THK) | 2 | |
| 1072139 | 17 PIN AS | 2 | |
| 7K1181 | 18 STRAP-CABLE | 4 |
