System And Components
268-9502 LINES GP-STICK -HIGH PRESSURES/N JLC1-UP; JLD1-UP
Group No: 268-9502
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 5I4188 | 1 BLOCK | 1 | |
| 1434159 | 2 CLIP | 6 | |
| 1737992 | 3 VALVE GP-MANUAL (AUXILIARY, SHUTOFF)(AUXILIARY, SHUTOFF) | 2 | |
| 1759057 | 4 TUBE AS | 1 | |
| 1759059 | 5 TUBE AS | 1 | |
| 1774223 | 6 FLANGE | 1 | |
| 2166540 | 7 HOSE AS | 1 | |
| 2696101 | 8 HOSE AS | 1 | |
| 2697991 | 9 TUBE AS | 1 | |
| 2697992 | 10 TUBE AS | 1 | |
| 1P3703 | 11 SEAL-RECTANGULAR | 5 | |
| 1P3704 | 12 SEAL-RECTANGULAR | 2 | |
| 1P3705 | 13 SEAL-RECTANGULAR | 2 | |
| 1P5767 | 14 FLANGE-HALF | 2 | |
| 5K9090 | 15 SEAL-O-RING | 1 | |
| 6V0400 | 16 FLANGE-HALF | 2 | |
| 7Y4038 | 17 CLAMP-HALF | 6 | |
| 8T4121 | 18 WASHER-HARD (11X21X2.5-MM THK) | 16 | |
| 8T4139 | 19 BOLT (M12X1.75X30-MM) | 8 | |
| 8T4183 | 20 BOLT (M12X1.75X40-MM) | 16 | |
| 8T4184 | 21 BOLT (M12X1.75X45-MM) | 8 | |
| 8T4194 | 22 BOLT (M12X1.75X50-MM) | 4 | |
| 8T4223 | 23 WASHER-HARD (13.5X25.5X3-MM THK) | 24 | |
| 8T4956 | 24 BOLT (M12X1.75X35-MM) | 4 | |
| 8T5005 | 25 BOLT (M10X1.5X70-MM) | 4 | |
| 8T5436 | 26 BOLT (M10X1.5X130-MM) | 4 | |
| 8T6685 | 27 BOLT (M10X1.5X110-MM) | 4 |
