System And Components
226-0629 LINES GP-STICK CYLINDER -DRIFT REDUCTION, RELIEF, STICK LOWERINGS/N JLC1-UP; JLD1-UP
Group No: 226-0629
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 0931294 | 1 CLAMP | 2 | |
| 1192379 | 2 SUPPORT AS | 1 | |
| 1538800 | 3 PLATE | 1 | |
| 1907696 | 4 PLATE | 1 | |
| 1907759 | 5 VALVE GP-LOAD CONTROL (STICK LOWERING) | 1 | |
| 2164624 | 6 SUPPORT AS | 1 | |
| 2258763 | 7 TUBE AS | 1 | |
| 2258765 | 8 TUBE AS | 1 | |
| 2258767 | 9 PIPE AS | 1 | |
| 2258769 | 10 PIPE AS | 1 | |
| 2263344 | 11 BRACKET AS | 1 | |
| 2263345 | 12 BLOCK | 1 | |
| 1087550 | 13 CLIP | 2 | |
| 1488340 | 14 CONNECTOR AS | 1 | |
| 3K0360 | SEAL-O-RING | 1 | |
| 6V8398 | SEAL-O-RING | 1 | |
| 6V8639 | CONNECTOR | 1 | |
| 1488368 | 15 ELBOW AS | 2 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 4J5477 | SEAL-O-RING | 1 | |
| 6V8627 | ELBOW | 1 | |
| 1P3703 | 16 SEAL-RECTANGULAR | 1 | |
| 3E8007 | 17 BOLT-SOCKET HEAD (M12X1.75X90-MM) | 4 | |
| 3V9744 | 18 SPACER | 1 | |
| 4J0520 | 19 SEAL-O-RING | 1 | |
| 5K9090 | 20 SEAL-O-RING | 1 | |
| 5Q4212 | 21 CLIP | 2 | |
| 6V8397 | 22 SEAL-O-RING | 2 | |
| 6V8398 | 23 SEAL-O-RING | 1 | |
| 6V8400 | 24 SEAL-O-RING | 1 | |
| 7Y4538 | 25 CLAMP-HALF | 2 | |
| 7Y4690 | 26 ELBOW | 1 | |
| 8T4121 | 27 WASHER-HARD (11X21X2.5-MM THK) | 6 | |
| 8T4139 | 28 BOLT (M12X1.75X30-MM) | 2 | |
| 8T4185 | 29 BOLT (M10X1.5X50-MM) | 1 | |
| 8T4186 | 30 BOLT (M10X1.5X40-MM) | 1 | |
| 8T4196 | 31 BOLT (M10X1.5X35-MM) | 4 | |
| 8T4223 | 32 WASHER-HARD (13.5X25.5X3-MM THK) | 12 | |
| 8T4244 | 33 NUT (M12X1.75-THD) | 2 | |
| 8T4648 | 34 BOLT (M12X1.75X70-MM) | 8 | |
| 7Y3732 | 35 CLIP | 2 |
