Assembly
100%

216-6830 BOOM GPS/N JLD1-UP

Group No: 216-6830
Part NumberPart NameQty
21668291 BOOM & BEARING AS1
1865476BUSHING2
09303642 SPACER (103X140X12-MM THK)1
25024153 PIN AS1
8T47804 BOLT (M20X2.5X30-MM)2
8T41235 WASHER (22X35X3.5-MM THK)2
09303496 WASHER (22X60X6-MM THK)2
16614887 SHIM (2-MM THK)2
09300908 SHIM (1-MM THK)1
13324279 SHIM (0.5-MM THK)1
093036310 SPACER (83X120X12-MM THK)1
4I461811 PIN AS1
8T495612 BOLT (M12X1.75X35-MM)6
8T422313 WASHER-HARD (13.5X25.5X3-MM THK)6
7Y239014 PLATE2
087595515 SPACER (93X130X8-MM THK)2
166148716 SHIM (2-MM THK)2
186563717 PIN1
166149718 SEAL-LIP TYPE2
