System And Components
234-4601 CYLINDER GP-STICKS/N L2K1-UP
Group No: 234-4601
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 7Y4956 | 1 LOCKNUT (M90X2-THD) | 1 | |
| 9X3607 | 2 SEAL AS | 1 | |
| 1915603 | 3 PISTON | 1 | |
| 1915604 | 4 RING | 2 | |
| 1915644 | 5 BUSHING | 1 | |
| 1915705 | 6 STOP | 1 | |
| 2316843 | 7 RING-SEAL | 1 | |
| 2426806 | 8 CYLINDER AS | 1 | |
| 2417342 | 8A BUSHING | 1 | |
| 2426811 | 9 ROD AS | 1 | |
| 2417342 | 9A BUSHING | 1 | |
| 1038345 | 10 RING-RETAINING | 1 | |
| 1076579 | 11 RING | 1 | |
| 1076933 | 12 STOP | 1 | |
| 1915602 | 13 HEAD | 1 | |
| 1915605 | 14 RING | 1 | |
| 1915643 | 15 RING-RETAINING | 1 | |
| 1915645 | 16 SEAL-BUFFER | 1 | |
| 1915646 | 17 SEAL-U-CUP | 1 | |
| 1915647 | 18 RING-BACKUP | 1 | |
| 1915648 | 19 SEAL-LIP TYPE | 1 | |
| 0950930 | 20 RING-RETAINING (EXTERNAL) | 2 | |
| 0951726 | 21 SEAL-O-RING | 1 | |
| 7Y4945 | 22 RING-BACKUP | 1 | |
| 7Y5239 | 23 BOLT-SOCKET HEAD (M24X3X100-MM) | 8 | |
| 2316844 | KIT-SEAL (STICK) | 1 |
