System And Components
365-4802 SUPPORT GP-AXLE HOUSING -CHASSISS/N TNM1004-UP
Group No: 365-4802
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 2G4080 | 1 SHAFT GP-DRIVE | 1 | |
| 3B8686 | 2 FITTING-GREASE (1/8-27 PTF) | 1 | |
| 6G7339 | 3 PLATE | 1 | |
| 6G7346 | 4 PLATE | 1 | |
| 6V0444 | 5 BEARING-SPHERICAL | 1 | |
| 4205462 | 6 PIN | 1 | |
| 8W9826 | 7 RING | 1 | |
| 8X0570 | 8 SHIM PACK (INCLUDES 33-SHIMS) | 1 | |
| 8X0572 | 9 WASHER-THRUST (127.5X152.4X3-MM THK) | 1 | |
| 8X0573 | 10 PIN | 1 | |
| 8X0585 | 11 PLATE | 1 | |
| 4347923 | 12 SUPPORT | 1 | |
| 3673098 | 13 CAP AS (REAR AXLE HOUSING) | 2 | |
| 1D4593 | 14 BOLT (5/8-11X5.5-IN) | 8 | |
| 1D4626 | 15 BOLT (7/8-9X2.75-IN) | 6 | |
| 8C6913 | 16 WASHER-HARD (24X41.5X4-MM THK) | 7 | |
| 5F9338 | 17 BOLT (1-8X7-IN) | 8 | |
| 7X2584 | 18 BOLT (M30X3.5X140-MM) | 16 | |
| 3045286 | 19 BOLT (7/8-9X10-IN) | 1 | |
| 3293701 | 20 WASHER (24X95X16-MM THK) | 2 | |
| 5P8247 | 21 WASHER-HARD (17X32X3.5-MM THK) | 8 | |
| 5P8250 | 22 WASHER (28X49X5-MM THK) | 8 | |
| 7X0449 | 23 NUT-FULL (7/8-9-THD) | 1 | |
| 2179902 | 24 WASHER (33X56X20-MM THK) | 32 |
