System And Components
527-0155 HOOD & GUARD GPS/N RBF20001-UP
Group No: 527-0155 · Commonality
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 4I0118 | 1 HOOK AS | 4 | |
| 7Y2853 | 2 SPACER (13X38X5-MM THK) | 3 | |
| 1358577 | 3 BOLT AS | 6 | |
| 1785678 | 4 BOSS | 4 | |
| 2447789 | 5 SPACER (19X38X3-MM THK) | 7 | |
| 2622603 | 6 SPACER (13.5X30X16-MM THK) | 7 | |
| 3272886 | 7 STRIKER AS | 2 | |
| 3272889 | 8 SHEET AS | 1 | |
| 3485409 | SEAL (13-DM) | ||
| 3361776 | 9 SUPPORT AS | 1 | |
| 3361777 | LINER | 1 | |
| 3374414 | 10 SUPPORT AS | 1 | |
| 3374455 | 11 SUPPORT AS | 1 | |
| 3374460 | 12 SUPPORT AS | 1 | |
| 3374461 | SHEET-RUBBER | 1 | |
| 3485409 | SEAL (16-DM) | ||
| 3374518 | 13 SUPPORT AS-ENCLOSURE | 1 | |
| 3374569 | 14 SHEET AS-SOUND SUPPRESSION | 1 | |
| 3374577 | 15 SHEET | 1 | |
| 3374578 | 16 SHEET AS-SOUND SUPPRESSION | 1 | |
| 3374604 | 17 SHEET | 1 | |
| 3374619 | 18 SHEET AS | 1 | |
| 3374625 | 19 SHEET AS | 1 | |
| 3374659 | 20 SUPPORT AS | 1 | |
| 3432465 | 21 BUMPER | 5 | |
| 3490480 | 22 SUPPORT AS | 2 | |
| 3504649 | 23 BRACKET AS | 1 | |
| 3504655 | 24 SHEET AS | 1 | |
| 3485409 | SEAL (4-DM) | ||
| 3536598 | 25 SUPPORT AS-ENCLOSURE | 1 | |
| 3490466 | SUPPORT AS | 1 | |
| 3536599 | LINER | 1 | |
| 3536763 | 26 SUPPORT AS | 1 | |
| 3536771 | 27 SUPPORT AS-ENCLOSURE | 1 | |
| 3536786 | 28 SUPPORT AS | 1 | |
| 3536788 | 29 SUPPORT AS | 1 | |
| 3568950 | 30 SHEET AS | 1 | |
| 3361792 | INSULATION | 1 | |
| 3485409 | SEAL (8-DM) | ||
| 3568958 | 31 SUPPORT AS-ENCLOSURE | 1 | |
| 3569056 | 32 SHEET AS-SOUND SUPPRESSION | 1 | |
| 3569312 | 33 SHEET AS-SOUND SUPPRESSION | 1 | |
| 3569314 | LINER | 1 | |
| 3569344 | 34 SHEET AS-SOUND SUPPRESSION | 1 | |
| 3569345 | 35 SHEET AS-SOUND SUPPRESSION | 1 | |
| 3569396 | LINER | 1 | |
| 3569346 | 36 SHEET AS-SOUND SUPPRESSION | 1 | |
| 3569347 | 37 SHEET AS-SOUND SUPPRESSION | 1 | |
| 3569405 | LINER | 1 | |
| 3635692 | 38 SUPPORT AS | 1 | |
| 3667211 | 39 SUPPORT AS | 1 | |
| 3667217 | 40 SPRING AS-GAS (ENGINE HOOD) | 1 | |
| 3719975 | 41 SHEET AS-SOUND SUPPRESSION | 1 | |
| 3743670 | 42 SUPPORT AS | 1 | |
| 3776721 | 43 SHEET AS | 1 | |
| 3776722 | LINER | 1 | |
| 3776723 | 44 SHEET AS-SOUND SUPPRESSION | 1 | |
| 3797363 | 45 SPRING | 1 | |
| 3797364 | 46 SUPPORT AS | 1 | |
| 3797366 | 47 SUPPORT AS | 1 | |
| 3922699 | 48 SUPPORT AS-SOUND SUPPRESSION | 1 | |
| 3938743 | 49 SHEET AS | 1 | |
| 4I7924 | WASHER (4.5X40X1.2-MM THK) | 4 | |
| 6P2216 | CAP (PUSH ON) | 4 | |
| 3374596 | SILENCER | 1 | |
| 3485409 | SEAL (1-DM) | ||
| 3938745 | 50 SHEET AS-SOUND SUPPRESSION | 1 | |
| 3938756 | 51 SUPPORT AS-SOUND SUPPRESSION | 1 | |
| 3938758 | 52 SUPPORT AS | 1 | |
| 9M2307 | WASHER (5.2X19X2-MM THK) | 2 | |
| 9M5732 | RIVET-POP | 2 | |
| 3719984 | SHEET-RUBBER | 1 | |
| 4181598 | 53 SUPPORT AS | 1 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 4 | |
| 8T3597 | NUT-WELD (M12X1.75-THD) | 4 | |
| 4336258 | 54 SUPPORT AS | 1 | |
| 7Y2916 | PIN-CLEVIS | 2 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 1 | |
| 8T3597 | NUT-WELD (M12X1.75-THD) | 1 | |
| 4336263 | 55 HOOD GP-ENGINE (HINGED) | 1 | |
| 4360787 | 56 SHEET AS-SOUND SUPPRESSION | 1 | |
| 4382397 | 57 COVER AS-SOUND SUPPRESSION (FUEL, HYDRAULIC TANKS) | 1 | |
| 4458143 | 58 SHEET AS | 1 | |
| 4I7924 | WASHER (4.5X40X1.2-MM THK) | 2 | |
| 6P2216 | CAP (PUSH ON) | 2 | |
| 4458222 | SILENCER | 1 | |
| 4661030 | 59 COVER AS-SOUND SUPPRESSION | 1 | |
| 3374676 | INSULATION | 3 | |
| 4734128 | 60 SHEET AS | 1 | |
| 4733487 | LINER | 1 | |
| 4984566 | 61 SHEET AS-SOUND SUPPRESSION | 1 | |
| 5105444 | 62 COVER AS | 1 | |
| 4I7924 | WASHER (4.5X40X1.2-MM THK) | 2 | |
| 6P2216 | CAP (PUSH ON) | 2 | |
| 5105446 | SILENCER | 1 | |
| 5118272 | 63 BRACKET | 1 | |
| 5118273 | 64 SHEET AS-SOUND SUPPRESSION | 1 | |
| 5256086 | 65 SHEET AS | 1 | |
| 3374558 | LINER | 1 | |
| 3485409 | SEAL (5-DM) | ||
| 5266477 | 66 HOOD GP-ENGINE (HINGED) | 1 | |
| 5267565 | 67 DOOR GP-ACCESS (PUMP COMPARTMENT) | 1 | |
| 5267566 | 68 DOOR GP-ACCESS (AIR CLEANER, BATTERY) | 1 | |
| 5267567 | 69 DOOR GP-ACCESS (RADIATOR, AFTERCOOLER, HYD OIL COOLER) | 1 | |
| 1358572 | 70 BOLT AS | 18 | |
| 1358573 | 71 BOLT AS | 63 | |
| 1358575 | 72 BOLT AS | 85 | |
| 0950841 | 73 PIN-COTTER | 2 | |
| 1703016 | 74 SPACER (19X32X2-MM THK) | 15 | |
| 3272884 | 75 BRACKET AS | 1 | |
| 5P0372 | 76 LOCK PIN | 2 | |
| 7X2550 | 77 BOLT (M12X1.75X110-MM) | 2 | |
| 7Y2854 | 78 SPACER (24X38X3-MM THK) | 3 | |
| 8T4121 | 79 WASHER-HARD (11X21X2.5-MM THK) | 22 | |
| 8T4133 | 80 NUT (M10X1.5-THD) | 5 | |
| 8T4136 | 81 BOLT (M10X1.5X25-MM) | 4 | |
| 8T4137 | 82 BOLT (M10X1.5X20-MM) | 18 | |
| 8T4139 | 83 BOLT (M12X1.75X30-MM) | 10 | |
| 8T4183 | 84 BOLT (M12X1.75X40-MM) | 4 | |
| 8T4184 | 85 BOLT (M12X1.75X45-MM) | 3 | |
| 8T4189 | 86 BOLT (M8X1.25X20-MM) | 8 | |
| 8T4223 | 87 WASHER-HARD (13.5X25.5X3-MM THK) | 7 | |
| 8T4224 | 88 WASHER-HARD (8.8X16X2-MM THK) | 16 | |
| 8T4821 | 89 WASHER (13.5X40X3-MM THK) | 10 |
