System And Components
541-3353 HEAD GP-PUMP -CONTROLS/N FEX1-UP
Group No: 541-3353
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 8T0269 | 1 BOLT-SOCKET HEAD (M6X1X20-MM) | 10 | |
| 2478738 | 2 SETSCREW | 1 | |
| 5C7261 | 3 NUT (M8X1.25-THD) | 1 | |
| 2069295 | 4 SEAL-O-RING | 1 | |
| 5413350 | 5 SPRING | 1 | |
| 5413351 | 6 RETAINER | 1 | |
| 2959577 | 7 SEAT | 1 | |
| 2069300 | 8 SEAL-O-RING | 1 | |
| 2959578 | 9 PISTON | 1 | |
| 2772545 | 10 SEAL-O-RING | 1 | |
| 3E8025 | 11 BOLT-SOCKET HEAD (M8X1.25X50-MM) | 2 | |
| 2478733 | 12 LEVER AS | 1 | |
| 5I8815 | 13 PIN | 1 | |
| 2496661 | 14 SEAL-O-RING | 2 | |
| 5I8814 | 15 RING-RETAINING | 2 | |
| 2478735 | 16 PIN AS | 1 | |
| 5I8790 | 17 PLUG | 1 | |
| 2478734 | 18 LEVER AS | 1 | |
| 5413348 | 19 LEVER AS | 1 | |
| 2496659 | 20 SEAL-O-RING | 1 | |
| 5I8809 | 21 SEAT-SPRING | 1 | |
| 5I8811 | 22 SPRING | 1 | |
| 5I8810 | 23 SPRING-RETURN | 1 | |
| 5I8813 | 24 RING-RETAINING | 1 | |
| 5413349 | 25 BODY AS-PUMP | 1 | |
| 5I8799 | 26 COVER | 1 | |
| 5I8800 | 27 LOCKNUT (M30X1.5-THD) | 1 | |
| 2959579 | 28 SETSCREW (M30X1.5X29-MM) | 1 | |
| 2959580 | 29 SCREW-SPECIAL | 1 | |
| 1608503 | 30 NUT (M10X1.5-THD) | 1 | |
| 2959575 | 31 SEAL-O-RING | 1 | |
| 2069301 | 32 SEAL-O-RING | 1 | |
| 2069299 | 33 SEAL-O-RING | 1 | |
| 5413352 | 34 SPRING | 1 | |
| 1297971 | 35 SPRING | 1 | |
| 2959583 | 36 SEAT | 1 | |
| 2959584 | 37 ROD | 1 | |
| 3494154 | 38 SLEEVE | 1 | |
| 5I8791 | 39 PISTON-COMPENSATOR | 1 | |
| 2069296 | 40 SEAL-O-RING | 1 | |
| 2069294 | 41 SEAL-O-RING | 1 | |
| 1297974 | 42 PIN | 1 | |
| 5I8802 | 43 COVER-PILOT | 1 | |
| 0962323 | 44 RING-RETAINING (EXTERNAL) | 1 | |
| 2496660 | 45 SEAL-O-RING | 1 | |
| 6V8213 | 46 BOLT-SOCKET HEAD (M8X1.25X70-MM) | 2 | |
| 8T8442 | 47 BOLT-SOCKET HEAD (M6X1X30-MM) | 2 | |
| 1899763 | 48 SEAL-O-RING | 1 | |
| 3476530 | 49 SEAL-RECTANGULAR | 9 | |
| 2496658 | 50 SEAL-O-RING | 3 | |
| 5I8812 | 51 COVER-BLOCK | 1 |
