576-9206 WIRING GP-CHASSISS/N GDW10001-UP; LHW10001-UP

Group No: 576-9206 · Commonality
Part NumberPart NameQty
20422811 STRAP-CABLE2
8T41722 BOLT (M10X1.5X80-MM)1
17722153 STRAP-DUAL CLAMP1
20240044 GROMMET1
20416115 STRAP-CABLE (DUAL)1
26673796 STRAP-CABLE2
3S20937 STRAP-CABLE33
5T63748 SPACER (11X20X40-MM THK)1
48378059 SPACER (11X20X65-MM THK)2
483780610 SPACER (11X20X56-MM THK)1
484145111 CLIP14
484145212 CLIP2
484145313 CLIP (RETAINER)6
484145414 CLIP-RETAINING7
484145615 STRAP-CABLE36
508055816 BRACKET AS1
8T3612NUT-WELD (M8X1.25-THD)3
517792317 PANEL GP-SWITCH (DISCONNECT)1
520114118 BRACKET AS3
8T3490NUT-WELD (M10X1.5-THD)2
5201142BRACKET1
520316319 WIRE AS1
524450620 BRACKET AS1
6V9632NUT-WELD (M6X1-THD)2
8T3490NUT-WELD (M10X1.5-THD)1
535722721 HARNESS AS-CHASSIS (AIR CLEANER)1
576684922 HARNESS AS-CAB (PRODUCT LINK 243, 083)1
576691723 BRACKET AS1
8T3490NUT-WELD (M10X1.5-THD)1
8T3612NUT-WELD (M8X1.25-THD)4
576927724 HARNESS AS-CHASSIS1
5F975725 GROMMET1
7K118126 STRAP-CABLE14
8T412127 WASHER-HARD (11X21X2.5-MM THK)34
8T413628 BOLT (M10X1.5X25-MM)4
8T413729 BOLT (M10X1.5X20-MM)26
8T417830 BOLT (M10X1.5X90-MM)2
8T646631 BOLT (M10X1.5X60-MM)1
9R794132 SOCKET AS1
9R7980COVER1
9X204233 SCREW-TRUSS HEAD (M6X1X12-MM)2
