System And Components
204-5154 PAN GP-OIL -DEEP SUMPPART OF 444-3546 PAN GP-OIL
Group No: 204-5154
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1W1564 | 1 SCREEN AS-SUCTION (ENGINE OIL PAN) | 1 | |
| 4B2363 | 2 PLUG-OIL DRAIN (ENGINE OIL PAN) | 2 | |
| 6F4868 | 3 GASKET | 2 | |
| 7C4715 | 4 CONNECTOR | 1 | |
| 7W0129 | 5 FLANGE | 1 | |
| 1112081 | 6 HOUSING-OIL | 1 | |
| 1499298 | 7 COVER | 1 | |
| 2045155 | 8 PAN AS-OIL | 1 | |
| 2045158 | 9 TUBE AS | 1 | |
| 2288925 | 10 TUBE-SUCTION | 1 | |
| 2288926 | 11 ADAPTER | 1 | |
| 2315867 | 12 CLAMP | 4 | |
| 1259794 | 13 SEAL-O-RING | 1 | |
| 0L1351 | 14 BOLT (3/8-16X0.875-IN) | 5 | |
| 0S1571 | 15 BOLT (3/8-16X1.75-IN) | 4 | |
| 0S1585 | 16 BOLT (1/2-13X1.5-IN) | 4 | |
| 0S1588 | 17 BOLT (3/8-16X1.25-IN) | 4 | |
| 0S1590 | 18 BOLT (3/8-16X2-IN) | 2 | |
| 0S1594 | 19 BOLT (3/8-16X1-IN) | 2 | |
| 1K6872 | 20 LOCKNUT (1/2-13-THD) | 4 | |
| 2B0858 | 21 PLUG-PIPE | 1 | |
| 3P0654 | 22 SEAL-O-RING | 2 | |
| 4B3140 | 23 COVER | 1 | |
| 5M2894 | 24 WASHER-HARD (10.2X18.5X2.5-MM THK) | 11 | |
| 5P7818 | 25 SEAL-O-RING | 1 | |
| 5P8245 | 26 WASHER-HARD (13.5X25.5X3-MM THK) | 8 | |
| 5P8872 | 27 SEAL-O-RING | 1 | |
| 6V5101 | 28 SEAL-O-RING | 1 | |
| 7X1547 | 29 SEAL-O-RING | 2 | |
| 8M9024 | 30 WASHER-HARD (10.2X22.5X5-MM THK) | 2 | |
| 9L1480 | 31 GASKET | 1 |
