System And Components
509-7245 CONNECTION GP-WATER -LH (CHG -00)AN ATTACHMENT
Group No: 509-7245
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 7W3272 | 1 GASKET | 1 | |
| 7W3709 | 2 ADAPTER-WATER | 1 | |
| 1451272 | 3 GASKET | 1 | |
| 1872126 | 4 PIPE AS | 1 | |
| 0S1590 | 5 BOLT (3/8-16X2-IN) | 8 | |
| 0S1594 | 6 BOLT (3/8-16X1-IN) | 4 | |
| 1S5772 | 7 GASKET | 1 | |
| 2B0858 | 8 PLUG-PIPE | 2 | |
| 2J3506 | 9 NUT-FULL (3/4-10-THD) | 8 | |
| 3V3308 | 10 WASHER-HARD (10.2X20.5X2.5-MM THK) | 16 | |
| 5P8248 | 11 WASHER-HARD (20X36.5X3.5-MM THK) | 16 | |
| 9S8752 | 12 NUT-FULL (3/8-16-THD) | 8 | |
| 1D4609 | 13 BOLT (3/4-10X3-IN) | 8 |
