System And Components
5N-3334 CLUTCH GPS/N BDN1-UP
Group No: 5N-3334
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 4L3527 | 1 PLATE-CLUTCH DRIVING | 1 | |
| 5L9652 | 2 HUB | 1 | |
| 8B7987 | 3 KEY-WOODRUFF | 1 | |
| 5L9653 | 4 NUT | 1 | |
| 5L9654 | LOCK | 1 | |
| 3H9571 | 5 PLATE-CENTER | 1 | |
| 5N9317 | 6 RING-DRIVE | 1 | |
| 7F8897 | 7 PLATE | 1 | |
| 3H9572 | 8 RING-ADJUSTMENT | 1 | |
| 3H9574 | 9 SLEEVE | 9 | |
| 4B4754 | 10 SHAFT | 1 | |
| 6L5151 | KEY-WOODRUFF | 2 | |
| 4B4792 | 11 YOKE AS | 1 | |
| 0S1591 | 12 BOLT (3/8-16X1.5-IN) | 2 | |
| 3B4506 | LOCKWASHER | 2 | |
| 1A1460 | 13 BOLT (1/2-13X2-IN) | 6 | |
| 3B4508 | LOCKWASHER | 6 | |
| 5B2404 | 14 RETAINER-BEARING | 1 | |
| 9S1354 | 15 NUT (5/8-18-THD) | 1 | |
| 6F0253 | LOCKWASHER | 1 | |
| 0S1617 | 16 BOLT (5/16-18X0.75-IN) | 1 | |
| 3F9556 | LOCKWASHER | 1 | |
| 5B2407 | LOCK | 1 | |
| 4B4716 | 17 COLLAR AS-SLEEVE | 1 | |
| 0L0639 | 18 BOLT (3/8-24X2.25-IN) | 2 | |
| 2L6267 | LOCKNUT (3/8-24-THD) | 2 | |
| 4B4758 | SHIM (0.06-IN THK) | 2 | |
| 5B2410 | 19 HOSE AS | 1 | |
| 4B4721 | 20 LINK | 8 | |
| 6L3967 | PIN | 8 | |
| 6L3964 | PIN-COTTER | 8 | |
| 6L3972 | 21 PIN | 4 | |
| 6L3961 | PIN-COTTER | 4 | |
| 1L4863 | WASHER-SPRING | 8 | |
| 4H0002 | 22 LEVER | 4 | |
| 3F3728 | 23 RING-SNAP | 1 | |
| 3N8125 | 24 PLATE AS-PRESSURE | 1 | |
| 3N8124 | 25 SPRING | 1 | |
| 3N8123 | LOCK PIN | 1 | |
| 8B7121 | 26 FITTING-HYDRAULIC (CLUTCH) | 2 | |
| 3N4899 | 27 SHAFT-CLUTCH | 1 | |
| 1L6931 | 28 SCREW AS-MACHINE (1/4-20X0.5-IN) | 2 | |
| 6B3223 | 29 CUP-BEARING | 2 | |
| 4B7270 | 30 CONE-BEARING | 2 | |
| 4B4810 | 31 LEVER AS-HAND | 1 | |
| 5B2406 | 32 CARRIER | 1 | |
| 3B8489 | 33 FITTING-GREASE (1/8-27 PTF)(CLUTCH)(1/8-27 THD) | 2 |
