System And Components
137-3430 PLATFORM AR-CAB -CUSTOMS/N 3ZN1-UP; 5LN1-UP; 7KN1-UP; 9PN1-UP; DMP1-UP
Group No: 137-3430
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1395200 | 1 PLATE | 1 | |
| 1406732 | 2 GASKET | 1 | |
| 5M3062 | 3 BOLT (3/8-16X0.75-IN) | 16 | |
| 5P1075 | 4 WASHER-HARD (10.2X22.5X3-MM THK) | 16 | |
| 6T4556 | 5 COVER | 1 | |
| 6T4557 | 6 GASKET | 1 | |
| 6T5067 | 7 LINER | 1 | |
| 1081328 | 8 HOOD & GUARD GP | 1 | |
| 1407696 | 9 COVER AS | 1 | |
| 5P8244 | WASHER-HARD (12X22.5X2.5-MM THK) | 2 | |
| 1059666 | 10 PLATFORM GP-CAB | 1 | |
| 1421652 | 11 PANEL GP-INSTRUMENT | 1 | |
| 1459134 | 12 FLOOR MAT | 1 | |
| 3T3635 | 13 HANDHOLD | 2 | |
| 1537033 | 14 DOOR AS | 1 | |
| 8E3303 | 15 STRIP | 2 | |
| 5P2228 | 16 BOLT (1/2-13X1-IN) | 12 | |
| 5P1076 | 17 WASHER-HARD (13.5X30X4-MM THK) | 10 | |
| 8E8382 | 18 PLATE AS | 1 | |
| 4F9101 | LUG (1/4-20-THD) | 4 | |
| 4M5283 | 19 BOLT (1/4-20X0.625-IN) | 4 | |
| 5P4115 | 20 WASHER-HARD (7.2X19X2-MM THK) | 4 | |
| 7G4823 | 21 STRAP | 1 | |
| 4B4276 | 22 WASHER (7X16X1.6-MM THK) | 2 | |
| 2D6235 | 23 LOCKNUT (1/4-20-THD) | 2 | |
| 7G4824 | 24 STRAP | 1 | |
| 7T0786 | 25 RETAINER AS | 1 | |
| 6V1790 | 26 PLUG-BUTTON | 3 | |
| 6P2216 | 27 CAP | 6 | |
| 1178863 | 28 LINER | 1 | |
| 1271046 | 29 LINER | 1 | |
| 7X2501 | 30 BOLT (1/4-20X1.25-IN) | 3 | |
| 7X0603 | 31 WASHER-HARD (9.9X35X2.5-MM THK) | 3 | |
| 8T4205 | 32 WASHER-HARD (7.2X14.5X2-MM THK) | 3 | |
| 3L0594 | 33 SPACER (8.7X15.9X15.9-MM THK) | 3 | |
| 1271045 | 34 LINER | 1 | |
| 1271043 | 35 LINER | 1 | |
| 1271044 | 36 LINER | 1 | |
| 1406731 | 37 PLATE AS | 1 | |
| 1406733 | 38 GASKET | 1 | |
| 0308838 | 39 SCREW (6-32X1-IN) | 6 | |
| 7D6922 | 40 LOCKNUT (6-32-THD) | 6 | |
| 8T2895 | 41 LOCK GP-CYLINDER | 1 | |
| 7F9223 | LOCKWASHER | 1 | |
| 8T5004 | SCREW-MACHINE (1/4-28X0.375-IN) | 1 | |
| 1395201 | 42 PLATE | 1 | |
| 1406736 | 43 GASKET | 1 | |
| 1406730 | 44 PLATE AS | 1 | |
| 1395202 | 45 PLATE | 1 | |
| 1406734 | 46 GASKET | 1 | |
| 1412241 | 47 PLATE AS | 1 | |
| 6P6926 | 48 SCREW-KNURLED | 2 | |
| 8T9384 | 49 BOLT (1/2-13X0.875-IN) | 2 | |
| 8T4223 | 50 WASHER-HARD (13.5X25.5X3-MM THK) | 2 | |
| 1418984 | 51 BRACKET AS | 2 | |
| 1F0748 | NUT-WELD (1/2-13-THD) | 1 | |
| 7T6299 | 52 GROMMET | 1 | |
| 5P0998 | 53 PLUG-SEAL | 2 | |
| 8T4189 | 54 BOLT (M8X1.25X20-MM) | 4 | |
| 4Y4281 | 55 PLUG | 1 | |
| 5P4116 | 56 WASHER-HARD (8.8X20.5X2-MM THK) | 4 | |
| 1744590 | 57 PLATE-INFORMATION (SERVICE INFORMATION NUMBERS) | 1 | |
| 8T9530 | 58 TACK | 6 | |
| 1081164 | PLATFORM GP-CAB | 1 | |
| 1081165 | INSTRUMENT GP | 1 | |
| 1187412 | PLATE | 1 | |
| 1187415 | BRACKET AS | 1 | |
| 8T9384 | BOLT (1/2-13X0.875-IN) | 2 | |
| 8T4223 | WASHER-HARD (13.5X25.5X3-MM THK) | 2 | |
| 5P1075 | WASHER-HARD (10.2X22.5X3-MM THK) | 2 | |
| 5P8167 | BOLT (3/8-16X0.625-IN) | 2 | |
| 8E8154 | FLANGE-OUTPUT | 1 | |
| 9N1995 | RIVET-POP | 6 |
