System And Components
3W-5366 SWEEP GPS/N 9KJ1-UP
Group No: 3W-5366
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1501955 | 1 PLATE | 8 | |
| 8C8843 | 2 BOLT (1-8X4.5-IN) | 4 | |
| 5G9958 | 3 BRACKET AS (RH) | 1 | |
| 5G9961 | 4 BRACKET AS (LH) | 1 | |
| 8T4835 | 5 BOLT (1/2-13X2-IN) | 8 | |
| 5P1076 | 6 WASHER-HARD (13.5X30X4-MM THK) | 12 | |
| 7C4948 | 7 EJECTOR AS | 1 | |
| 1329651 | 8 SWEEP AS | 1 | |
| 1P2772 | 9 SPACER (1.031X1.219X0.75-IN THK) | 4 | |
| 3W6528 | 10 TUBE AS | 2 | |
| 5G9963 | 11 PLATE AS | 2 | |
| 5G9965 | 12 GUARD AS | 1 | |
| 5G9970 | 13 GUARD AS | 1 | |
| 7K3673 | BOSS | 2 | |
| 6K3632 | 14 LOCKNUT (1-8-THD) | 2 | |
| 8C8844 | 15 BOLT (1-8X5-IN) | 2 | |
| 8P5244 | 16 WASHER (33.3X69.8X6.35-MM THK) | 4 | |
| 9S5187 | 17 MOUNTING | 6 | |
| 8E6891 | 18 BLOCK AS | 2 | |
| 8E9532 | 19 SPACER | 2 | |
| 8T9389 | BOLT (1/2-13X2.75-IN) | 8 | |
| 6K3632 | 20 LOCKNUT (1-8-THD) | 4 | |
| 1P2772 | 21 SPACER (1.031X1.219X0.75-IN THK) | 8 | |
| 8P5244 | 22 WASHER (33.3X69.8X6.35-MM THK) | 8 | |
| 6T1698 | 23 MOUNT | 8 | |
| 8T9393 | 24 BOLT (5/8-11X1.5-IN) | 4 | |
| 8T4122 | 25 WASHER-HARD (17X32X3.5-MM THK) | 4 | |
| 8C8842 | 26 BOLT (3/4-10X4-IN) | 4 | |
| 7X0582 | 27 WASHER-HARD (20X44.5X6-MM THK) | 4 | |
| 7S4994 | 28 CAP AS-RAIN (EXHAUST) | 1 | |
| 7X0366 | 29 BOLT (3/4-10X2-IN) | 4 | |
| 7X0564 | 30 WASHER-HARD (20X51X3-MM THK) | 4 |
