3N-4681 TRANSMISSION GP-MARINE2.00:1 RATIO. SPECIFICATION NO. 34004
Group No: 3N-4681
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 2N9418 | 1 BREATHER AS (TRANSMISSION) | 1 | |
| 7L2175 | 2 SEAL-O-RING | 1 | |
| 0L1351 | 3 BOLT (3/8-16X0.875-IN) | 11 | |
| 6L5208 | 4 COVER-TOP | 1 | |
| 6L5209 | 5 GASKET | 1 | |
| 4L9764 | 6 GASKET | 1 | |
| 0S1594 | 7 BOLT (3/8-16X1-IN) | 9 | |
| 6L5219 | 8 KEY | 2 | |
| 4M8610 | 9 RING-PISTON | 2 | |
| 4L9829 | 10 BOLT | 2 | |
| 4L9769 | 11 PLATE-LOCK | 1 | |
| 4L9758 | 12 RING-PISTON | 1 | |
| 4H1641 | 13 PIN-SPRING | 4 | |
| 4L9779 | 14 SPRING-RELEASE | 32 | |
| 4L9811 | 15 SETSCREW | 4 | |
| 4L9782 | 16 SPRING-RELEASE | 32 | |
| 3N6915 | 17 SEAL-RUBBER | 1 | |
| 7L4090 | 18 SEAL-O-RING | 1 | |
| 4L9760 | 19 GASKET | 1 | |
| 3N0710 | 20 BEARING AS-ROLLER | 1 | |
| 4L9770 | 21 WASHER-RETAINING | 1 | |
| 6L6378 | 22 SHAFT-OUTPUT | 1 | |
| 4L9822 | 23 SEAL-LIP TYPE | 2 | |
| 4L9801 | 24 RETAINER-BEARING | 1 | |
| 0T0320 | 25 BOLT (7/16-14X1.25-IN) | 7 | |
| 4L9768 | 26 SHIM (0.005 IN THICK) | 3 | |
| 3N0709 | SHIM (0.007 IN THICK) | 1 | |
| 5N5881 | 27 GEAR-TRANSFER (42-TEETH) | 1 | |
| 1F6660 | 28 NIPPLE-PIPE | 1 | |
| 6L6372 | 29 GEAR-SHAFT (54-TEETH) | 1 | |
| 6L4336 | 30 PAN-GEAR | 1 | |
| 9F2247 | 31 PLUG-PIPE (1/8-27-THD) | 2 | |
| 5L3199 | 32 SPRING | 2 | |
| 5L3201 | 33 PIN | 1 | |
| 6L2319 | 34 RACE & ROLLER AS | 1 | |
| 2K2711 | 35 RACE-BEARING INNER | 1 | |
| 5L3196 | 36 WASHER-RETAINING | 1 | |
| 6L6376 | 37 KEY | 1 | |
| 2L1740 | 38 RING-DRIVE | 1 | |
| 4L9744 | 39 PLATE-LOCK | 1 | |
| 1A2209 | 40 BOLT (3/8-24X1.25-IN) | 3 | |
| 5N5888 | 41 RETAINER GP-BEARING | 1 | |
| 5D0353 | 42 BOLT-LOCKING (3/8-16X1-IN) | 6 | |
| 5D0353 | 43 BOLT-LOCKING (3/8-16X1-IN) | 6 | |
| 6L5218 | 44 KEY | 2 | |
| 7T2031 | 45 SHAFT-INPUT | 1 | |
| 4L9761 | 46 GASKET | 1 | |
| 2L1701 | 47 BOLT (5/8-18X1.5-IN) | 3 | |
| 4L9771 | 48 WASHER-RETAINING | 2 | |
| 4L9797 | 49 SPIDER-DRIVE | 1 | |
| 4H8101 | 50 SEAL-LIP TYPE | 1 | |
| 6L3618 | 51 RETAINER-BEARING | 1 | |
| 4L9765 | 52 GASKET | 1 | |
| 6L3616 | 53 CONNECTOR | 1 | |
| 6L3621 | 54 TUBE AS | 1 | |
| 6L6369 | 55 PINION-GEAR | 2 | |
| 2N4619 | 56 BLOCK-RUBBER | 26 | |
| 5L3202 | 57 PIN | 1 | |
| 4L3220 | 58 BALL BEARING | 2 | |
| 3N6913 | 59 HOUSING-MAIN | 1 | |
| 1T0143 | DOWEL (0.3749 IN LONG) | 2 | |
| 4L9793 | DOWEL (0.4375 IN LONG) | 2 | |
| 6L5224 | 60 SPIDER-CLUTCH | 2 | |
| 7L7782 | 61 PLATE-CLUTCH | 14 | |
| 6L2179 | 62 PLATE-CLUTCH | 14 | |
| 3N6915 | 63 SEAL-RUBBER | 1 | |
| 7L8273 | 64 PIN | 2 | |
| 5N2745 | 65 PLATE-HUB & BACK | 2 | |
| 7T2029 | 66 NUT | 1 | |
| 7T2028 | LOCK | 1 | |
| 7T2027 | SHIM (0.5-MM THK) | 1 | |
| 2H3903 | SETSCREW-SOCKET | 1 | |
| 4L9825 | 67 BALL BEARING | 2 | |
| 0S1594 | 68 BOLT (3/8-16X1-IN) | 14 | |
| 4L9757 | 69 RING-PISTON | 1 | |
| 4L9752 | 70 PIN | 1 | |
| 4L9751 | 71 SLEEVE-DRIVE | 1 | |
| 4L9763 | 72 GASKET | 1 | |
| 4L9783 | 73 RING-PISTON | 2 | |
| 7L8274 | 74 RETAINER-SPRING | 1 | |
| 6L2194 | 75 RING-RETAINING | 1 | |
| 5N2744 | 76 CARRIER-PISTON | 2 | |
| 6L4335 | 77 PISTON-CLUTCH | 2 | |
| 4L9820 | 78 RING-RETAINING | 2 | |
| 2B7412 | 79 PLUG-PIPE | 1 | |
| 6L4329 | 80 COVER-BOTTOM | 1 | |
| 4L9762 | 81 GASKET | 1 | |
| 5N5889 | 82 RETAINER GP-BEARING | 1 | |
| 5D0353 | 83 BOLT-LOCKING (3/8-16X1-IN) | 6 | |
| 4L9772 | 84 SPACER | 2 | |
| 5L3197 | 85 PIN | 1 | |
| 5L3199 | SPRING | 1 | |
| 9F2247 | PLUG-PIPE (1/8-27-THD) | 1 | |
| 5N5881 | 86 GEAR-TRANSFER (42-TEETH) | 1 | |
| 5L7723 | 87 RACE-BEARING | 2 | |
| 8T0230 | 88 BEARING AS | 2 | |
| 0S1616 | 89 BOLT (1/4-20X1-IN) | 2 | |
| 4L9767 | 90 GASKET | 1 | |
| 3N6911 | 91 HOUSING-FRONT | 1 | |
| 2L1701 | 92 BOLT (5/8-18X1.5-IN) | 1 | |
| 3H2617 | 93 PIN-SPRING | 2 | |
| 7T2030 | 94 SHAFT-REVERSE CLUTCH | 1 | |
| 5L7722 | 95 RACE & ROLLER AS | 2 | |
| 2J3118 | 96 BOLT-LOCKING (3/8-16X1.25-IN) | 4 | |
| 2H6234 | 97 RING-SNAP | 2 | |
| 3N6914 | 98 CARRIER-BEARING | 1 | |
| 4L3191 | 99 PLATE-COVER | 1 | |
| 0S1594 | 100 BOLT (3/8-16X1-IN) | 10 | |
| 8B7016 | 101 LINK | 1 | |
| 8B7245 | 102 CHAIN | 1 | |
| 6F5272 | 103 CLIP | 1 | |
| 5B6172 | WASHER (9.7X19X0.8-MM THK) | 1 | |
| 5L7820 | 104 EYEBOLT | 2 | |
| 2L1808 | 105 COVER | 1 | |
| 2L1388 | GASKET | 1 | |
| 0S1571 | 106 BOLT (3/8-16X1.75-IN) | 6 | |
| 2B7457 | 107 PLUG-PIPE | 1 | |
| 4L9750 | 108 COVER-STRAINER | 1 | |
| 2H3939 | 109 ELBOW | 1 | |
| 4L9748 | 110 GASKET-PLATE | 1 | |
| 4L9747 | 111 ELEMENT-STRAINER (TRANSMISSION OIL) | 1 | |
| 6B9081 | 112 BUSHING-REDUCER | 1 | |
| 4L9746 | 113 HOSE AS | 1 | |
| 5K9243 | 114 ELBOW-FLARED | 1 | |
| 3B8485 | 115 ELBOW (TRANSMISSION) | 1 | |
| 4L9810 | 116 PLATE-LOCK | 1 | |
| 2L1701 | 117 BOLT (5/8-18X1.5-IN) | 3 | |
| 6L6367 | 118 FLANGE-PROPELLER | 1 | |
| 1A2029 | 119 BOLT (3/8-16X1.125-IN) | 18 | |
| 0L0364 | 120 LOCK | 2 | |
| 3N4378 | 121 MANIFOLD AS | 1 | |
| 7H3171 | 122 PLUG-PIPE | 5 | |
| 9F2247 | 123 PLUG-PIPE (1/8-27-THD) | 1 | |
| 0S1591 | 124 BOLT (3/8-16X1.5-IN) | 1 | |
| 2B7457 | 125 PLUG-PIPE | 2 | |
| 4L9753 | 126 PUMP AS-MARINE XMSN OIL | 1 | |
| 3B6554 | 127 ELBOW | 1 | |
| 1N7284 | 128 BOLT-12 POINT HEAD (3/8-16X2.5-IN) | 2 | |
| 3N9384 | 129 TUBE AS-OIL GAUGE | 1 | |
| 6T4013 | 130 VALVE AS-CONTROL | 1 | |
| 1T0765 | 131 BOLT (3/8-16X1-IN) | 2 | |
| 3N9385 | 132 GAUGE AS-OIL LEVEL (DIPSTICK) | 1 | |
| 2L5895 | 133 GASKET-PIPE | 1 | |
| 3H9675 | 134 PIN-SPRING | 1 | |
| 6L3622 | 135 TUBE AS-LUBRICATION | 1 | |
| 6L3623 | 136 PISTON | 1 | |
| 4L9567 | 137 SPRING | 1 | |
| 2L5893 | 138 PIN-SPRING (.39CM DIA) | 2 | |
| 2L5894 | PIN-SPRING (0.24CM DIA) | 1 | |
| 5L1990 | PLATE-INSTRUMENT | 1 | |
| 4B4158 | SCREW-DRIVE (NO 4X0.25-IN) | 4 | |
| 7L8497 | KIT-CLUTCH SERVICE (MARINE TRANSMISSION) | 1 |
