System And Components
295-5261 SWITCH GP-PUSH BUTTON -BATTERY ISOLATIONS/N CXM383-538
Group No: 295-5261
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3618527 | 1 SWITCH AS-PUSH BUTTON (PARKING BRAKE) | 1 | |
| 1S6249 | DOWEL | 2 | |
| 0951577 | SEAL-O-RING | 1 | |
| 0963001 | SETSCREW-SOCKET (M5X0.8X6-MM) | 2 | |
| 1415027 | SPRING | 2 | |
| 2286143 | 2 SWITCH GP-PARKING BRAKE (PARKING BRAKE) | 1 | |
| 2105732 | ENCAPSULANT | 1 | |
| 8T8729 | PIN-CONNECTOR (16-GA TO 20-GA) | 6 | |
| 0328870 | PIN-SPRING | 3 | |
| 1028805 | KIT-RECEPTACLE (6-PIN) | 1 | |
| 3214625 | SLEEVE (30-CM) | ||
| 1257876 | TUBE-HEAT SHRINK (17.78-MM DIA)(10-CM) | ||
| 3033574 | 3 BUTTON-PUSH | 1 | |
| 2286144 | 4 RING | 1 | |
| 6K6307 | 5 SEAL-O-RING | 1 | |
| 3046323 | 6 SCREW (M5X0.8X6-MM) | 1 | |
| 3046324 | 7 SCREW (M5X0.8X20-MM) | 1 |
