System And Components
363-3887 LINES GP-AUXILIARY SEA WATERS/N SSW1-UP
Group No: 363-3887
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3633888 | 1 TUBE AS | 1 | |
| 4310053 | 2 HOSE | 1 | |
| 3633892 | 3 HOSE | 1 | |
| 3699174 | 5 BRACKET | 1 | |
| 0S1585 | 6 BOLT (1/2-13X1.5-IN) | 1 | |
| 0S1591 | 7 BOLT (3/8-16X1.5-IN) | 1 | |
| 0S1595 | 8 BOLT (1/2-13X1.25-IN) | 1 | |
| 1333260 | 9 SPACER (11X19X10-MM THK) | 1 | |
| 1A1460 | 10 BOLT (1/2-13X2-IN) | 1 | |
| 1F7958 | 11 NUT-FULL (1/2-13-THD) | 1 | |
| 1W8793 | 12 SPACER (13.8X30X20-MM THK) | 1 | |
| 2M1538 | 13 STUD-TAPERLOCK (3/8-16X1.6-IN) | 1 | |
| 5M2894 | 14 WASHER-HARD (10.2X18.5X2.5-MM THK) | 2 | |
| 5P8245 | 15 WASHER-HARD (13.5X25.5X3-MM THK) | 3 | |
| 6V1867 | 16 CLIP (SLOT) | 3 | |
| 6V1868 | 17 CLIP (TAB) | 3 | |
| 6V1869 | 18 GROMMET (65-MM ID) | 3 | |
| 7D1649 | 19 WASHER-HARD (13.5X32X5-MM THK) | 1 | |
| 8T4984 | 20 CLAMP-HOSE | 8 | |
| 9S8752 | 21 NUT-FULL (3/8-16-THD) | 1 | |
| 4264149 | 22 PLUG | 1 | |
| 1J9671 | 23 SEAL-O-RING | 1 |
