System And Components
368-5642 LINES GP-FUELS/N SSW1-UP
Group No: 368-5642
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 0910081 | 1 SPACER (10.5X20X10-MM THK) | 2 | |
| 1230555 | 2 MANIFOLD | 1 | |
| 3274448 | 3 VALVE GP-CHECK | 1 | |
| 3635209 | 4 LINE AS-FUEL | 1 | |
| 3779548 | 5 ADAPTER AS | 1 | |
| 2147568 | SEAL-O-RING | 1 | |
| 2287089 | SEAL-O-RING | 1 | |
| 3779546 | ADAPTER-CROSS | 1 | |
| 3826909 | 6 LINE AS-FUEL | 1 | |
| 3826910 | 7 LINE AS-FUEL | 1 | |
| 0S1588 | 8 BOLT (3/8-16X1.25-IN) | 1 | |
| 1833399 | 9 CONNECTOR AS | 1 | |
| 6V8636 | CONNECTOR | 1 | |
| 2147568 | SEAL-O-RING | 1 | |
| 2287089 | SEAL-O-RING | 1 | |
| 3893708 | 10 PLUG AS | 2 | |
| 2147568 | SEAL-O-RING | 1 | |
| 3603679 | PLUG-CONNECTOR (9/16-18-THD) | 1 | |
| 1D4539 | 12 BOLT (5/16-18X2.5-IN) | 2 | |
| 2501424 | 15 ELBOW AS | 2 | |
| 6V8724 | ELBOW | 1 | |
| 2147568 | SEAL-O-RING | 1 | |
| 2287089 | SEAL-O-RING | 1 | |
| 3256994 | 16 CLIP (SLOT) | 1 | |
| 3256995 | 17 CLIP (TAB) | 1 | |
| 3295451 | 18 ADAPTER AS | 1 | |
| 9X0261 | ADAPTER | 1 | |
| 2147566 | SEAL-O-RING | 1 | |
| 2147568 | SEAL-O-RING | 1 | |
| 3537954 | 19 GROMMET | 1 | |
| 3537956 | 20 GROMMET | 1 | |
| 5S0003 | 22 NUT (5/16-18-THD) | 2 | |
| 8T1889 | 24 CLIP (SLOT) | 1 | |
| 8T1890 | 25 CLIP (TAB) | 1 | |
| 9M1974 | 26 WASHER-HARD (8.8X16X2-MM THK) | 4 | |
| 9S8752 | 27 NUT-FULL (3/8-16-THD) | 1 | |
| 9X6458 | 29 WASHER-HARD (10.2X22.5X3-MM THK) | 3 | |
| 3960425 | 30 CONNECTOR AS | 1 | |
| 8T1779 | CONNECTOR | 1 | |
| 2147568 | SEAL-O-RING | 1 | |
| 2287089 | SEAL-O-RING | 1 | |
| 3218610 | 31 CONNECTOR AS | 1 | |
| 9X2297 | CONNECTOR | 1 | |
| 2147568 | SEAL-O-RING | 1 | |
| 2287089 | SEAL-O-RING | 1 |
