470-3023 ENCLOSURE GP-GENERATORS/N XJ51-UP

Group No: 470-3023
Part NumberPart NameQty
14281941 RIVET14
16608952 COVER2
16608973 COVER1
22825364 SWITCH GP-PUSH BUTTON1
47030245 BASE AS-ENCLOSURE1
47030266 EXHAUST GP1
47030547 PLATE-DUCT1
47263668 ENCLOSURE GP1
09512709 SETSCREW-SOCKET (M12X1.75X30-MM)8
129318010 LOCKNUT (M12X1.75-THD)8
131354011 LOCKNUT (M8X1.25-THD)2
260667212 BOLT (M8X1.25X20-MM)6
6V818213 NUT (3/4-10-THD)6
7X036614 BOLT (3/4-10X2-IN)6
8T412115 WASHER-HARD (11X21X2.5-MM THK)84
8T413316 NUT (M10X1.5-THD)38
8T413617 BOLT (M10X1.5X25-MM)46
8T422318 WASHER-HARD (13.5X25.5X3-MM THK)8
8T422419 WASHER-HARD (8.8X16X2-MM THK)8
8T499420 WASHER-HARD (20X36.5X3.5-MM THK)12
9X825721 WASHER (17.5X30X3.5-MM THK)8
5P592422 SEAL (15.8-M)
197804023 SEAL-RUBBER (58-DM)
1428240KEY2
