System And Components
384-8014 SHUTOFF GP-AIRAN ATTACHMENT
Group No: 384-8014
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1W1250 | 1 COVER | 2 | |
| 1W1251 | 2 GASKET | 5 | |
| 1W7391 | 3 GASKET | 1 | |
| 2W5213 | 5 HOUSING | 1 | |
| 8T6761 | PLUG-PIPE (1-11-1/2 NPT THD) | 2 | |
| 2W9584 | 6 PIPE | 1 | |
| 2W9585 | 7 PIPE | 1 | |
| 4W6964 | 8 BRACKET | 2 | |
| 7E8550 | 9 FLANGE | 2 | |
| 7N5080 | 10 GASKET-MANIFOLD | 12 | |
| 7N5085 | 11 FLANGE | 12 | |
| 7N5089 | 12 GASKET | 12 | |
| 7W1944 | 13 RETAINER | 2 | |
| 7W6957 | 14 SOLENOID GP-SHUTOFF | 1 | |
| 1343804 | 15 ELBOW | 12 | |
| 1448275 | 16 SHUTOFF GP-AIR | 1 | |
| 0L1351 | 18 BOLT (3/8-16X0.875-IN) | 2 | |
| 1653929 | 19 BOLT (3/8-16X1.5-IN) | 8 | |
| 0S1619 | 20 BOLT (3/8-16X3-IN) | 2 | |
| 0T0573 | 21 BOLT (3/8-16X2.75-IN) | 4 | |
| 1A2029 | 22 BOLT (3/8-16X1.125-IN) | 18 | |
| 6V5839 | 23 WASHER (11X21X2.5-MM THK) | 2 | |
| 5M2894 | 24 WASHER-HARD (10.2X18.5X2.5-MM THK) | 126 | |
| 5P0076 | 25 BOLT-12 POINT HEAD (3/8-16X1.5-IN) | 96 | |
| 6V3319 | 27 SEAL-O-RING | 2 | |
| 6V3917 | 28 SEAL-O-RING | 4 | |
| 6V5101 | 29 SEAL-O-RING | 12 | |
| 6V5167 | 30 SEAL-O-RING | 4 | |
| 8M7145 | 31 WASHER (10.2X28.5X5-MM THK) | 2 | |
| 8T6761 | 32 PLUG-PIPE (1-11-1/2 NPT THD) | 2 | |
| 8T6765 | 33 PLUG-PIPE (1/4-18-THD) | 1 | |
| 1345505 | 34 FILM-INFORMATION (CLOSE) | 1 | |
| 1345482 | 35 FILM-INFORMATION (OPEN) | 1 | |
| 0S1594 | 36 BOLT (3/8-16X1-IN) | 18 |
