System And Components
543-9883 BOX GP-INSTRUMENT PANEL -RHAN ATTACHMENT
Group No: 543-9883
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 2922654 | 1 SLEEVE (19-CM) | ||
| 9X9591 | 2 CONVERTER GP-ELECTRICAL (PULSE WIDTH MODULATED) | 1 | |
| 1735413 | 3 CLAMP | 2 | |
| 1072482 | 4 GASKET | 6 | |
| 1108909 | 5 MOUNT-FLEXIBLE | 6 | |
| 1169723 | 6 DIAL-VERNIER | 1 | |
| 1229458 | 7 POTENTIOMETER (1000-OHM) | 1 | |
| 1239694 | 8 HORN | 1 | |
| 1272331 | 9 SWITCH AS-ROTARY (ENGINE CONTROL) | 1 | |
| 1314891 | 10 GASKET | 1 | |
| 1319131 | 11 SEAL-CONNECTOR (76-MM ID) | 2 | |
| 1328489 | 12 NUT-RING | 1 | |
| 2212498 | 13 WIRE AS (8-GA, BLACK) | 1 | |
| 3321841 | 14 FILM-WARNING (SHOCK HAZARD, READ OMM) | 1 | |
| 3321842 | 15 FILM-WARNING (HOT SURFACE, HANDS CLEAR) | 1 | |
| 2319911 | 16 BRACKET | 1 | |
| 2379022 | 17 HARNESS AS-PANEL (SPEED CONTROL) | 1 | |
| 2421553 | 18 FILM-IDENTIFICATION (PANEL SWITCHES) | 1 | |
| 2423282 | 19 LAMP AS-LED (24-VOLT, RED) | 2 | |
| 2502298 | 20 LAMP AS-LED (AMBER, 24-VOLT) | 1 | |
| 2502299 | 21 LAMP AS-LED (24-VOLT, GREEN) | 1 | |
| 8T8729 | PIN-CONNECTOR (16-GA TO 20-GA) | 2 | |
| 2678623 | 22 DISPLAY GP-MONITOR (MARINE POWER DISPLAY) | 1 | |
| 3170808 | 23 SEAL-O-RING | 4 | |
| 3901208 | 24 SHROUD | 1 | |
| 4460608 | 25 BOX AS-INSTRUMENT | 1 | |
| 4468339 | 26 FILM-IDENTIFICATION (CONTROL PANEL) | 1 | |
| 4468342 | 27 PLATE AS | 1 | |
| 7T1099 | LINK | 3 | |
| 9F6445 | NUT-WELD (1/4-20-THD) | 1 | |
| 4470662 | 28 HARNESS AS-PANEL (MARINE POWER DISPLAY) | 1 | |
| 4476618 | 29 RELAY (250-VOLT)(POWER) | 1 | |
| 4476618 | 29A RELAY (250-VOLT)(RESET) | 1 | |
| 4476618 | 29B RELAY (250-VOLT)(ENGINE CONTROL SWITCH) | 1 | |
| 4476618 | 29C RELAY (250-VOLT)(HORN) | 1 | |
| 4476619 | 30 RELAY (250-VOLT)(START ENABLE) | 1 | |
| 4476619 | 30A RELAY (250-VOLT)(RUN 1) | 1 | |
| 4476619 | 30B RELAY (250-VOLT)(STOP 1) | 1 | |
| 4476619 | 30C RELAY (250-VOLT)(STOP ENABLE) | 1 | |
| 4476619 | 30D RELAY (250-VOLT)(RUN 2) | 1 | |
| 4476619 | 30E RELAY (250-VOLT)(STOP 2) | 1 | |
| 4476621 | 31 BLOCK-DIODE | 7 | |
| 4476622 | 32 BLOCK-TERMINAL | 2 | |
| 4476623 | 33 COVER-TERMINAL | 1 | |
| 4476625 | 34 COVER-TERMINAL | 1 | |
| 4484865 | 35 STRIP-CONTACT | 1 | |
| 4484866 | 36 GASKET | 1 | |
| 4485024 | 37 MARKER AS-TERMINAL | 1 | |
| 4485064 | 38 SWITCH (EMERGENCY STOP) | 1 | |
| 1566450 | 39 SCREW-PAN HEAD (6-32X15.88-MM) | 4 | |
| 1783339 | 40 SCREW (8-32X0.5-IN) | 26 | |
| 1H4393 | 41 LOCKWASHER | 2 | |
| 1028802 | 42 KIT-RECEPTACLE (2-PIN) | 4 | |
| 3T4405 | 43 SWITCH GP-TOGGLE (THROTTLE SELECT) | 1 | |
| 4B4863 | 44 WASHER (4.7X11X1.2-MM THK) | 2 | |
| 4D1836 | 45 SWITCH-TOGGLE (TORQUE LIMIT) | 1 | |
| 4D1836 | 45A SWITCH-TOGGLE (PROTECTION OVERRIDE) | 1 | |
| 5M2894 | 46 WASHER-HARD (10.2X18.5X2.5-MM THK) | 4 | |
| 5P0537 | 47 WASHER-HARD (7.2X14.5X2-MM THK) | 4 | |
| 6D5801 | 48 LOCKNUT (8-32-THD) | 24 | |
| 7C4910 | 49 SEAL (WASHER) | 1 | |
| 7N8001 | 50 SWITCH GP-TOGGLE (PRELUBRICATION OVERRIDE) | 1 | |
| 7N8001 | 50A SWITCH GP-TOGGLE (CRANK OVERRIDE) | 1 | |
| 9S8750 | 51 NUT-FULL (1/4-20-THD) | 2 | |
| 9S8752 | 52 NUT-FULL (3/8-16-THD) | 4 | |
| 7K1181 | 53 STRAP-CABLE | 3 |
