System And Components
532-7560 PANEL GP-ELECTRONICS/N CK21-UP
Group No: 532-7560
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 5685429 | 1 BRACKET-LATCH | 1 | |
| 0966166 | 2 WASHER-HARD (4.5X9X1-MM THK) | 3 | |
| 1313540 | 3 LOCKNUT (M8X1.25-THD) | 2 | |
| 1434456 | 4 INSULATOR | 2 | |
| 1694516 | 5 INSULATOR | 3 | |
| 1921329 | 6 BOLT-SPECIAL | 2 | |
| 1H4393 | 7 LOCKWASHER | 1 | |
| 2253109 | 8 SCREW-TRUSS HEAD (M4X0.7X14-MM) | 3 | |
| 2253322 | 9 SCREW-TRUSS HEAD (M6X1X10-MM) | 6 | |
| 2337742 | 10 SCREW (M4X0.7X7-MM) | 1 | |
| 2434174 | 11 STRAP AS-GROUND | 1 | |
| 2495492 | 12 GUARD-SWITCH | 1 | |
| 2591027 | 13 STOP-DOOR | 2 | |
| 2643636 | 14 BOLT-SOCKET HEAD (M6X1.0X20-MM) | 4 | |
| 2657124 | 15 STOP-DOOR | 2 | |
| 2664324 | 16 SWITCH-LIMIT (TERMINAL BOX) | 1 | |
| 2666450 | 17 TERMINAL | 2 | |
| 2679125 | 18 SOCKET | 1 | |
| 3429023 | 19 SCREW-PAN HEAD (M3X0.5X10-MM) | 4 | |
| 3445673 | 20 NUT (M6X1-THD) | 8 | |
| 3445674 | 21 NUT (M8X1.25-THD) | 1 | |
| 3445675 | 22 NUT (M10X1.5-THD) | 3 | |
| 3453758 | 23 PLUG-BUTTON | 1 | |
| 3534515 | 24 SWITCH GP-TOGGLE (MAINTENANCE MODE) | 1 | |
| 1028803 | KIT-RECEPTACLE (3-PIN) | 1 | |
| 3E3390 | PIN-CONNECTOR (16-GA TO 18-GA) | 3 | |
| 3630371 | 25 CONTROLLER AS | 1 | |
| 3776488 | 26 HANDLE | 1 | |
| 4465618 | 27 SWITCH AS (EMERGENCY STOP) | 1 | |
| 4557867 | 28 CAP AS | 1 | |
| 8C6354 | CAP-RECEPTACLE (ET CONNECTOR) | 1 | |
| 4B4274 | 29 WASHER (5.5X13X1.2-MM THK) | 2 | |
| 5156506 | 30 RECEPTACLE | 1 | |
| 5296895 | 31 FRAME AS | 1 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 2 | |
| 8T3612 | NUT-WELD (M8X1.25-THD) | 10 | |
| 8T8874 | NUT-WELD (M5X0.8-THD) | 10 | |
| 5296896 | 32 SUPPORT AS | 1 | |
| 2057047 | INSERT-THREADED (M4X0.7-THD) | 5 | |
| 6V9632 | NUT-WELD (M6X1-THD) | 2 | |
| 8T3612 | NUT-WELD (M8X1.25-THD) | 7 | |
| 5D9629 | ROD | 2 | |
| 5296900 | 33 PANEL AS | 1 | |
| 5296902 | 34 PANEL GP-ELECTRONIC (RECEPTACLE) | 1 | |
| 5296904 | 35 BRACKET AS | 1 | |
| 7T1099 | LINK | 4 | |
| 8T3612 | NUT-WELD (M8X1.25-THD) | 17 | |
| 5D9629 | ROD | 4 | |
| 5296908 | 36 CIRCUIT BREAKER AS (800-AMPERE) | 1 | |
| 5296910 | 37 BRACKET | 1 | |
| 5296911 | 38 MOUNTING GP-TRANSFORMER | 1 | |
| 5301955 | 39 HARNESS AS-PANEL (MAIN) | 1 | |
| 5327525 | 40 PANEL GP-ELECTRONIC (SUBPANEL) | 1 | |
| 5357290 | 41 HARNESS AS-PANEL (SHORE POWER) | 1 | |
| 5476098 | 42 FILM GP | 1 | |
| 5482416 | 43 HARNESS AS-PANEL (BREAKER) | 1 | |
| 5524808 | 44 BARRIER AS | 1 | |
| 5533668 | 45 PLATE | 1 | |
| 5661957 | 46 BUS BAR (GROUND) | 1 | |
| 5662917 | 47 BRACKET AS | 1 | |
| 4K9230 | NUT-WELD (10-32-THD) | 4 | |
| 5D9629 | ROD | 2 | |
| 5664907 | 48 BUS BAR (NEUTRAL) | 1 | |
| 5666714 | 49 PANEL GP-ELECTRONIC | 1 | |
| 5666717 | 50 BUS BAR | 3 | |
| 5738628 | 51 COVER | 1 | |
| 5C8312 | 52 NUT (M4X0.7-THD) | 2 | |
| 5P4116 | 53 WASHER-HARD (8.8X20.5X2-MM THK) | 8 | |
| 6V5210 | 54 SCREW-MACHINE (M4X0.7X10-MM) | 2 | |
| 6V9491 | 55 SCREW-MACHINE (M4X0.7X20-MM) | 4 | |
| 6V9672 | 56 SCREW-MACHINE (M4X0.7X16-MM) | 2 | |
| 7K1181 | 57 STRAP-CABLE | 36 | |
| 7X2536 | 58 BOLT (M8X1.25X14-MM) | 4 | |
| 7Y7388 | 59 SCREW-BUTTON HEAD (M5X0.8X12-MM) | 2 | |
| 8C8585 | 60 SCREW-BUTTON HEAD (M10X1.5X20-MM) | 8 | |
| 8C9660 | 61 WASHER (4.6X7.9X0.8-MM THK) | 7 | |
| 8T4121 | 62 WASHER-HARD (11X21X2.5-MM THK) | 8 | |
| 8T4138 | 63 BOLT (M6X1X20-MM) | 2 | |
| 8T4189 | 64 BOLT (M8X1.25X20-MM) | 45 | |
| 8T4195 | 65 BOLT (M10X1.5X30-MM) | 5 | |
| 8T4224 | 66 WASHER-HARD (8.8X16X2-MM THK) | 41 | |
| 8T4908 | 67 BOLT (M8X1.25X25-MM) | 1 | |
| 8T4971 | 68 BOLT (M6X1X30-MM) | 2 | |
| 8T8998 | 69 SCREW-MACHINE (M6X1X20-MM) | 4 | |
| 8T7500 | 70 SCREW-MACHINE (M4X0.7X35-MM) | 2 | |
| 9P0719 | 71 GROMMET | 1 | |
| 9X2038 | 72 WASHER (7X19X2-MM THK) | 4 | |
| 9X8256 | 73 WASHER (6.6X12X2-MM THK) | 12 | |
| 5P5637 | 74 SEAL (0.97-M) | ||
| 5P5637 | 74A SEAL (0.7-M) | ||
| 1320338 | 75 WASHER-PLASTIC (13X31.7X0.8-MM THK) | 2 |
