System And Components
129-1521 GENERATOR GPS/N 7YR1-UP
Group No: 129-1521
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1010375 | 1 STATOR AS | 1 | |
| 1316177 | 2 ROTOR AS | 1 | |
| 1112413 | 3 FAN-GENERATOR | 1 | |
| 6I0748 | 4 DEFLECTOR | 3 | |
| 7E6574 | 5 COVER-DRIP | 1 | |
| 3H5932 | 6 BOLT (5/16-18X4.5-IN) | 4 | |
| 5P0537 | 7 WASHER-HARD (7.2X14.5X2-MM THK) | 9 | |
| 5L2087 | 8 SPACER (9.25X13.72X50.8-MM THK) | 4 | |
| 0S1615 | 9 BOLT (1/4-20X0.75-IN) | 4 | |
| 3V5035 | 10 SPACER (0.302X0.54X1.03-IN THK) | 1 | |
| 1295842 | 11 COVER GP-ACCESS | 1 | |
| 5N3167 | SEAL-RING | 3 | |
| 5N3176 | PLUG-BUTTON | 3 | |
| 6D7128 | SEAL-O-RING | 4 | |
| 8P7065 | PLUG-BUTTON | 2 | |
| 8T9587 | SEAL-O-RING | 2 | |
| 0302284 | PLUG-BUTTON | 4 | |
| 1310460 | 12 BRACKET (LH) | 1 | |
| 1310461 | 13 BRACKET (RH) | 1 | |
| 1308402 | 14 FRAME AS | 2 | |
| 7E6578 | 15 PANEL | 2 | |
| 4P3152 | 16 ROTOR-EXCITER | 1 | |
| 9Y5816 | 17 STATOR-EXCITER | 1 | |
| 1181324 | 18 BRACKET-BEARING | 1 | |
| 5M6214 | 19 PLUG (1/8-27 PTF) | 2 | |
| 6I2737 | 20 RETAINER-BEARING | 2 | |
| 9F7022 | 21 BOLT (1/4-20X1.5-IN) | 1 | |
| 1B2714 | 22 BOLT (1/4-20X2.5-IN) | 4 | |
| 4P3153 | 24 SPACER (20.6X77X27.8-MM THK) | 1 | |
| 6I0088 | 25 COVER AS-EXCITER | 1 | |
| 1N7219 | 26 CHANNEL-RUBBER | 1 | |
| 1122563 | 27 SCREEN AS | 1 | |
| 4M5282 | 28 BOLT (1/4-20X1.5-IN) | 4 | |
| 1296598 | 29 COVER | 1 | |
| 1311909 | 30 PANEL AS | 1 | |
| 4F8711 | PLUG-BUTTON | 2 | |
| 5N3174 | PLUG-BUTTON | 4 | |
| 6K9593 | PLUG-BUTTON | 1 | |
| 8P7065 | PLUG-BUTTON | 8 | |
| 1296596 | 31 COVER AS | 1 | |
| 1296597 | 32 BOX AS | 1 | |
| 4K9230 | NUT-WELD (10-32-THD) | 8 | |
| 2905567 | 33 HEAT SINK AS | 1 | |
| 1A9579 | 35 BOLT (5/16-18X1.5-IN) | 4 | |
| 9M1974 | 36 WASHER-HARD (8.8X16X2-MM THK) | 8 | |
| 7E5940 | 37 FILM-INFORMATION (GENERATOR WIRING DIAGRAM) | 1 | |
| 1264421 | 38 SCREEN AS | 1 |
