System And Components
332-9652 LINES GP-AUXILIARY HYDRAULIC -REACH BOOM, HIGH PRESSURES/N SD21-UP
Group No: 332-9652
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 4I8784 | 1 FLANGE | 1 | |
| 8T4223 | 2 WASHER-HARD (13.5X25.5X3-MM THK) | 8 | |
| 1211948 | 3 PLATE | 1 | |
| 1380524 | 4 PLATE | 2 | |
| 1936655 | 5 PLATE | 2 | |
| 2479303 | 6 PLATE | 1 | |
| 2479305 | 7 PLATE | 4 | |
| 3372543 | 8 PLATE | 3 | |
| 3372544 | 9 PLATE | 4 | |
| 3372546 | 10 TUBE AS | 1 | |
| 3372547 | 11 TUBE AS | 1 | |
| 3372548 | 12 TUBE AS | 1 | |
| 3568022 | 13 HOSE AS | 1 | |
| 3568077 | 14 HOSE AS | 1 | |
| 4471703 | 15 BOLT (M16X2X120-MM) | 2 | |
| 4471704 | 16 BOLT (M16X2X90-MM) | 10 | |
| 4471707 | 17 BOLT (M16X2X60-MM) | 26 | |
| 4471711 | 18 BOLT (M16X2X50-MM) | 18 | |
| 4512175 | 19 WASHER-HARD (17.5X30X3.5-MM THK) | 64 | |
| 4532837 | 20 BOLT (M16X2X55-MM) | 4 | |
| 4532839 | 21 BOLT (M16X2X100-MM) | 4 | |
| 4795670 | 22 TUBE AS | 1 | |
| 1240909 | 23 CLIP | 14 | |
| 1287514 | 24 CLIP | 14 | |
| 1P3704 | 25 SEAL-RECTANGULAR | 2 | |
| 1P3705 | 26 SEAL-RECTANGULAR | 4 | |
| 1P3706 | 27 SEAL-RECTANGULAR | 1 | |
| 1P5767 | 28 FLANGE-HALF | 4 | |
| 5P8077 | 29 FLANGE-HALF | 4 | |
| 7X0584 | 30 WASHER-HARD (13.5X20.5X2-MM THK) | 4 | |
| 7X2550 | 31 BOLT (M12X1.75X110-MM) | 4 | |
| 8T4184 | 32 BOLT (M12X1.75X45-MM) | 4 | |
| 8T4194 | 33 BOLT (M12X1.75X50-MM) | 4 |
